SM482PLUS_TRM(Ver2.7_CS21.02) - 第194页
Page +$1:+$ 194 SM482 PLUS Power Block Diagram(6/8) AM03-020599B AM03-020125A AM03-006960A AM03-006961B DRIVER PE15 U -M2 3~ M W V E L3 SERVO r -SD1 L1 t DRIVER DRIVER PE16 U -M3 3~ M VW E V M 3~ -M4 U PE17 W E SERVO r -…
Page
+$1:+$
193
Power Block Diagram(5/8)
SM482
PLUS
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-020595B CABLE ASSY-TB-FS/CP/MC;B 1 SM48_PW113_LT
2 AM03-006954A CABLE ASSY-AC_RELAY_ POWER 1 SM48N_PW005
3 AM03-005702A CABLE ASSY-MON_DISTRIB_ADAPTOR 1 SM471_PW068
4 AM03-005519A CABLE ASSY-USB_HUB_ADAPTOR 1 SM471_PW067
5 AM03-006899A CABLE ASSY-PS1_2_AC_POWER_T1L 1 SM48_PW111
6 AM03-006906A CABLE ASSY-PS1_PS2_PW_T1L 1 SM48_PW201
7 AM03-006955A CABLE ASSY-PS3_4_AC_POWER_T2L 1 SM48N_PW112
8 AM03-006956A CABLE ASSY-PS3_PS4_PW_T2L 1 SM48N_PW202
9 AM03-006901A CABLE ASSY-PS1_2_DC_POWER_T1L 1 SM48_PW120
10 AM03-006896A CABLE ASSY-Z_DRV_PW 1 SM48_PW027
11 AM03-006902A CABLE ASSY-PS3_4_DC_POWER_T2L 1 SM48N_PW103
Page
+$1:+$
194
SM482
PLUS
Power Block Diagram(6/8)
AM03-020599B
AM03-020125A
AM03-006960A
AM03-006961B
DRIVER
PE15
U
-M2
3~
M
WV E
L3
SERVO
r
-SD1
L1
t
DRIVERDRIVER
PE16
U
-M3
3~
M
VW E V
M
3~
-M4
U
PE17
W E
SERVO
r
-SD2
L2L1
t
SERVO
t
L3
r
-SD3
L2 L3L1
2
DRIVER
E
PE18
-M5
3~
M
W
UV
L2
-SD4
r
L1
t
SERVO
L3
50W
SW-AXIS
750W
X-AXIS
1KW
Y2-AXIS
1KW
Y1-AXIS
2 2
2
2
22L1
22L3
22L2
22T
22R
(SM48_PW018-01)
0.75mm(BLK)
(SM48_PW019) (SM48_PW020)
-MC1
3Ø AC220V
22R
22S
22T
(LC1D096BD-9A,440V)
0.75mm(BLK) 0.75mm(BLK)
FROM CP2
2.5A(Max 19A)
2.5 mm (BLK)
2.5 mm (BLK)
17C17B
21B
19C
21C
15B
13B
15C
13C
18B
22B
20B
16B
14B13A
15A
17A
19A
21A
1
3
5
2
4
6
(SM482_PW000_LT)
1
2
3 4
Page
+$1:+$
195
Power Block Diagram(6/8)
SM482
PLUS
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-006873A CABLE ASSY-CP2_TB1-MC1 1 SM48_PW008
2 AM03-006958A CABLE ASSY-MC1_TB1 1 SM48_PW009
3 AM03-014671A CABLE ASSY-SW_WD_SERVO_POWER 1 AM03-006959A SM48_PW018
4 AM03-006960A CABLE ASSY-X_Y2_SERVO_POWER 1 SM48-PW019
5 AM03-006961A CABLE ASSY-Y1_SERVO_POWER 1 SM48_PW020
