CM108B
USB Audio Single Chip
Datasheet Revision: 1.11 www.cmedia.com.tw
Page 20 / 24 Copyright© C-Media Electronics Inc.
8 Electrical characteristics
8.1 Absolute maximum rating
Symbol
Parameters
Value
Unit
Dvmin
Min. digital supply voltage
– 0.3
V
Dvmax
Max. digital supply voltage
+ 6
V
Avmin
Min. analog supply voltage
– 0.3
V
Avmax
Max. analog supply voltage
+ 6
V
Dvinout
Voltage on any digital input or output pin
–0.3 to +5.5
V
Avinout
Voltage on any analog input or output pin
–0.3 to +3.96
V
TBstgB
Storage temperature range
-40 to +125
°C
ESD (HBM)
ESD human body mode
+-4000
V
ESD (MM)
ESD machine mode
+-200
V
Latch Up
JEDEC standard no.78, Mar. 1997
200
mA
8.2 Operation conditions
Operation conditions
Min
Typ
Max
Unit
Analog supply voltage
4.5
5.0
5.5
V
Digital supply voltage
4.5
5.0
5.5
V
Total power consumption
-
37.25
mA
Suspend-mode power consumption
-
1.58
uA
Operating ambient temperature
-20
-
70
°C
8.3 Electrical parameters
Min.
Typ.
Max.
Unit
DAC (10K Ohm Loading)
Resolution
-
16
-
Bits
THD + N (-3dBr) @1KHz
-
-72
-
dB
SNR
-
93
-
dB
Silent SNR
-
98
-
dB
Dynamic range
-
92
-
dB
Frequency response 48KHz
20
-
20K
Hz
Frequency response 44.1KHz
20
-
20K
Hz
Full Scale Output voltage (rms)
-
0.995
-
Vrms
DAC (32 Ohm loading)
Resolution
-
16
-
Bits
THD + N (-3dBr) @1KHz
-
-70
-
dB
SNR
-
93
-
dB
Silent SNR
-
98
-
dB
Dynamic range
-
92
-
dB
Frequency response 48KHz
20
-
20K
Hz
Frequency response 44.1KHz
20
-
20K
Full Scale Output voltage (rms)
-
0.442
-
Vrms
Output Volume Control
Volume Control Initial Value
-10
dB
CM108B
USB Audio Single Chip
Datasheet Revision: 1.11 www.cmedia.com.tw
Page 21 / 24 Copyright© C-Media Electronics Inc.
Volume Control Level
-37
-
0
dB
Volume Control Step
-
38
-
Steps
ADC
Resolution
-
16
-
bit
THD + N (-3dBr) @1KHz
-
-84
-
dB
SNR
-
90
-
dB
Dynamic range
-
88.5
-
dB
Frequency response 48KHz
100
-
20K
Hz
Frequency response 44.1KHz
100
-
20K
Hz
Input range
0
-
2.88
Vpp
Microphone Input
Boost gain
-
12/22 (EEPROM)
-
dB
Gain Adjustment Initial Value
8
dB
Gain adjustment range
-12
-
23
dB
Gain adjustment steps
-
36
-
Steps
Mixer Gain Initial Value
-7
dB
Mixer gain adjustment
-23.0
-
8.0
dB
Mixer gain adjustment steps
-
32
-
Steps
CM108B
USB Audio Single Chip
Datasheet Revision: 1.11 www.cmedia.com.tw
Page 22 / 24 Copyright© C-Media Electronics Inc.
9 Package information
48-Lead Thin Plastic Quad Flatpack (LQFP)
Symbol
Dimensions in mm
Minimum
Normal
Maximum
A
8.90
－
9.10
B
6.90
－
7.10
C
8.90
－
9.10
D
6.90
－
7.10
E
－
0.50
－
F
－
0.20
－
G
1.35
－
1.45
H
－
－
1.60
I
－
0.10
－
J
0.45
－
0.75
K
0.10
－
0.20
α
0°
－
7°
Note: Outline Dimensions are shown in millimeters
