PN 141-400 www.formfactor.com Microscopes • 55
Revision 57, February, 2023 Probe Station Accessories
LEICA OBJECTIVES
131-788 — Leica 25 X Eye Pieces, High
Performance, Extended Relief for Leica
Microscopes
Features
• Wide-field eyepieces compatible with eyeglasses
Specifications
• 25X magnification
131-789 — 30x Eyepieces for Leica S6/S8
Microscopes
Features
• Wide field eye-pieces
Specifications
• 30X magnification
132-109 — Leica 0.63 Auxiliary Lens for S8 Leica
Microscope
Features
• Objective for Leica S8 StereoZoom
microscope
• Increases field of view
• Increases working distance
Specifications
• 0.63X magnification
• 100 mm (3.9 in) working distance
• Apo chromatic optical design
PN 141-400 www.formfactor.com Microscopes • 56
Revision 57, February, 2023 Probe Station Accessories
Microscope Adapters, Mounting Plates, and Accessories
ADAPTERS
111486 — Microscope Adapter, A-Zoom and
Motic PSM-1000/229
Features
• For microscope movement ranges larger than XY
50 x 50 mm (2 x 2 in)
• Use d with PA300, PM300 and IceShield PS200
Compatibility
• PA300, PM300, PA200, PM8, PM5, DSP, BEP
120103 — Microscope Adapter, Optem/229
Features
• For microscope movement ranges larger than
XY 50 x 50 mm (2 x 2 in)
Compatibility
• PA300, PM300, PA200, PM8, PM5, DSP, BEP
120586 — Microscope Adapter, Mitutoyo FS70x-S/229
Features
• For microscope movement ranges XY 50 x 50 mm (2
x 2 in) and larger
• Compatible with FS70 with original Mitutoyo focus
rack 378 -062 only
• Use d with PA300 and PM300
Compatibility
• PA300, PM300, PA200, PM8, PM5, DSP, BEP
132712 — Microscope Adapter, Optem
Features
• Required for use with OPTEM Zoom 70 video microscope
Compatibility
• PA200 Bl ueRay, PA200 DS BlueRay
133915 — Microscope Adapter, Olympus
SZ2-STP/229
Features
• For adapter Olympus SZ2-STP
Compatibility
• PA300, PM30 0, PA200, PM8, PM5, DSP, BEP
142730 — Microscope Adapter, Motic
SMZ-168/171/229
Features
• For microscope movement ranges of 50 x 50 mm
(2 x 2 in) and 100 x 100 mm (3.9 x 3.9 in)
• Adapts Motic SMZ168/171 for microscope
movement
Compatibility
• PA300, PM30 0, PA200, PM8, PM5, DSP, BEP
MOUNTING PLATES
158-064 — Microscope Mounting Kit, Leica, Manual
Transport
Features
• Dovetail mounting block for Leica S6 and S8
• Adapts standard dovetail to bonder pin common
to stereo zoom microscopes
• Universal design for Summit 11000B, 12000B,
S300 and legacy probe stations
Compatibility
• Summit, S300, Alessi, MTS
PN 141-400 www.formfactor.com Microscopes • 57
Revision 57, February, 2023 Probe Station Accessories
ACCESSORIES
102-363 — Mitutoyo Video Adapter, 1.0X Magnification
Features
• Connect video camera to micr oscope for
remote viewing
Specifications
• 1X magnification
