Page SAMSUNG TECHWIN 90 SM421 X-Y Frame Ass’y (1/5) 13 4 4 3 2 1 3 4 9 5 6 7 8 9 9 10 11 12 14 15 16 4 9
Page
SAMSUNG TECHWIN
89
SM421
Air Ass’y - SM421F
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J6701028A AIR CYLINDER BDAS 6X15-CS11TA2 J9083179A
2 J6711156A HOSE NIPPLE [M-5H-4](D/C) 1
3 J6711132A FITTING [M-5HL-4] J1300120
4 J9060412A SM321 VACUUM SENSOR BD J9060337A
5 J67110180C ROTARY JOINT J67111808
6 J3204002A AIR PRESSURE SENSOR [MPX5100AP] 6
7 AM03-003693A ASSY AIR SM421F AIR MODLUE MAC_SMC J904426E
Page
SAMSUNG TECHWIN
90
SM421
X-Y Frame Ass’y (1/5)
13
4
4
3
2
1
3
4
9
5
6
7
8
9
9
10
11
12
14
15
16
4
9
Page
SAMSUNG TECHWIN
91
SM421
X-Y Frame Ass’y (1/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J90541020A X-Y_ASSY J90541020A 1
1 J7054256A CUSHION BRACKET Y[J7054256A] 1
2 J7354024A CABLE CUSHION Y[J7354024A] 1
3 J3212022A LIMIT SENSOR [EE-SX674] 3
4 J7354023A CABLE CUSHION X[J7354023A] 3
5 J71541083B GUIDE_CABLE_CHAIN_X 1
6 FC11-000005A Y2_PLATE 1 J71541082B
7 J71541081A Y1_PLATE 1 J71541081B
8 J7154268A HEAD_BASE 1 J71541020B
9 J7054255A CUSHION BRACKET X[J7054255A] 3
10 J70541129B SENSOR_DOG_Y 1
11 J70541116A COVER_Y_CABLE_DUCT_BRK J70541116A 1
12 FC09-001021A BKT_CABLE_CHAIN_Y J70541114A 1 J70541114A
13 J70541038A SENSOR_DOG_X J70541038A 2
14 J66070076A LM_GUIDE [SSR15X2W2UUC1+940LHY-II] 2 J66070076B
15 J72540016E INNER GUIDE-MAT 3
16 J71541086A HEAD_TOP_COVER J71541086A 1
