Page SAMSUNG TECHWIN 11 8 SM421 E lectric Device Ass’y (1/4) 5 AIR PRESSURE SAFEGUARD OVERRIDE MAIN SWITCH 6 ST OP RESET SELECT FEEDER CHANGE ST AR T READY 2 1 4 7 10 Front Power Panel Ass'y MAIN SWITCH SAFEGUARD OV…
Page
SAMSUNG TECHWIN
117
SM421
Electric Panel Ass’y (2/2)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J90511022A HEAD R MOTOR DRIVER ASSY 1
2 J31531049A SERVO MOTOR DRIVER(750W)[MCDDT3520] 1 J3153056A
3 J31531050A SERVO MOTOR DRIVER(1KW)[MDDDT5540] 2 J3153057A
4 J31531051A SERVO MOTOR DRIVER(100W)[MADDT1205] 1 J3153055A
AM10-000107A RELAY 1
Page
SAMSUNG TECHWIN
118
SM421
Electric Device Ass’y (1/4)
5
AIR PRESSURE
SAFEGUARD
OVERRIDE
MAIN SWITCH
6
ST
OP
RESET
SELECT
FEEDER
CHANGE
ST
AR
T
READY
2
1
4
7
10
Front Power Panel Ass'y
MAIN SWITCH
SAFEGUARD
OVERRIDE
MAIN SWITCH
9
8
3
Page
SAMSUNG TECHWIN
119
SM421
Electric Device Ass’y (1/4)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J91681007A ELECTRIC_DEVICE_ASSY J91681007A 1
AM03-001243A SM421N_ELECTRIC_DEVICE_ASSY 1 SM421N
J91681020A SM421F_ELECTRIC_DEVICE_ASSY 1 SM421F
1 J52011002A MINI_KEYBOARD 5510UH 1
2 J53011032A LCD_MONITOR_15 1 J53011015A
3 J31091015A FAN FILTER 120MM(NMB) 2 J6309025A
4 J7452038A MOUSE PAD - OPTICAL[J7452038A] 1
5 J47131010A TOWER_LAMP PTE-APV-302-RYG(510) 1
6 J90601023B TEACHING_BOX 1
7 J52021011A OPTICAL MOUSE 1 J52021006A
8 J3406005A LOAD SWITCH 1 J34060005B
9 J3409029A KEYLOCK SWITCH[AS6M-2KT2PB] 1
10 HP04-000075 FAN FILTER_ METAL_120MM 2
