Page SAMSUNG TECHWIN 12 SM421 F eeder Base Ass’y - DC (2/4) 4 3 8 7 6 6 6 6 1 2 5 6 9
Page
SAMSUNG TECHWIN
11
SM421
Feeder Base Ass’y - DC (1/4)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J90571015A FEEDER_BASE_ASSY_FRONT-DC J90571015A 1
1 J90600354B FEEDERBASE_RIGHT_COVER_PCB_ND 1 J9060354A
2 J90600353B FEEDERBASE_LEFT_COVER_PCB_ND 1 J9060353A
3 J6711256A COUPLER[KD-M5-SA34697KR] 56
4 J1301188 FITTING [KQ2L04-M5/PL4-M5M/SQL04-M5] 4
5 AM03-000696A ASSY,BOARD-FBLD 1 J9060349D
6 AM03-000695A ASSY,BOARD-FBRD 1 J9060350D
7 J70570261C TOP PLATE-DC 1
Page
SAMSUNG TECHWIN
12
SM421
Feeder Base Ass’y - DC (2/4)
4
3
8
7
6
6
6
6
1
2
5
6
9
Page
SAMSUNG TECHWIN
13
SM421
Feeder Base Ass’y - DC (2/4)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J6711104A STRAIGHT FITTING[KQ2H04-00/PU4] 1
2 J6711256A COUPLER[KD-M5-SA34697KR] 1
3 J6703033A SPEED CON[AS2201F-01-06S] 1
4 J6703034A SPEED CON[ASP330F-01-06S] 1
5 J6711247A ELBOW FITTING[PT18EF] 2
6 J6711001A ELBOW FITTING 1
7 J67110119B UNION Y FITTING [KQ2U04-06] 1
8 J67050004B SILENCER AN101-01 2
9 J6702021A SOLENOID VALVE [K180-4E1-21-DC24V] 1
