Page SAMSUNG TECHWIN 20 SM421 C onveyor Ass’y (2/5) 18 11 3 4 12 17 8 2 6 16 2 14 7 5 13 10 9 19 20 15 1 21
Page
SAMSUNG TECHWIN
19
SM421
Conveyor Ass’y (1/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J90531083A CONV_ASSY_LR J90531083A 1
1 J70531109A MANUAL_HANDLE J70531109A 1
2 J3212004A PHOTO SENSOR 1
3 J1300509 BALL BEARING 4 J6601008A
4 J6601109A BALL BEARING[608ZZ] 2
5 J6601126A BALL BEARING[F608ZZ] 2
6 J6602074A TIMING BELT[025-XL-396-AJ] 1
7 J6609012A PULLEY-WIDTH [20-XL-025] 2
8 J7053194A BEARING NUT [J7053194A] 2
9 J7053725A SUPPORT-WIDE ADJUST[J7053725A] 2
10 J7053726A SCREW STAND[J7053726A] 2
11 J70530749B DOG ADJUST J70530749B 1
12 J7053661B WIDTH TENSION SPACER[J7053661B] 2
13 J7053662A TENSION BEARING PIN[J7053662A] 2
14 J71530404B FIX STAND 2
15 J7053695B STOPPER[J7053695B] 1
16 J7153326A WIDTH PULLEY COLLAR[J7153326A] 2
17 J7053660A TENSION BKT[J7053660A] 2
18 J6614007A LEAD SCREW[DCM16 + 648.5L] 2
19 J7053787A CONVEYOR CHIP COVER-L[J7053787A] 1
Page
SAMSUNG TECHWIN
20
SM421
Conveyor Ass’y (2/5)
18
11
3
4
12
17
8
2
6
16
2
14
7
5
13
10
9
19
20
15
1
21
Page
SAMSUNG TECHWIN
21
SM421
Conveyor Ass’y (2/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1
J31081058A SERVO MOTOR[MSMA012P1A01] 1 J3108062A
2 J1300509 BALL BEARING 4 J6601008A
3 J6601109A BALL BEARING[608ZZ] 2
4 J6601126A BALL BEARING[F608ZZ] 2
5 J6602030A TIMING BELT [258-3M-9] 1
6 J6609012A PULLEY-WIDTH [20-XL-025] 2
7 J6609015B PULLEY-MOTOR [P32-3M-9] 1
8 J7053194A BEARING NUT [J7053194A] 2
9 J7053725A SUPPORT-WIDE ADJUST[J7053725A] 2
10 J7053726A SCREW STAND[J7053726A] 2
11 J7053661B WIDTH TENSION SPACER[J7053661B] 2
12 J7053662A TENSION BEARING PIN[J7053662A] 2
13 J71530404B FIX STAND 2
14 J7053780A BRACKET-SERVO MOTOR[J7053780A] 1
15 J70530748B STOPPER-FRONT 2 J7053748A
16 J7153326A WIDTH PULLEY COLLAR[J7153326A] 2
17 J7153330A PULLEY SHAFT[J7153330A] 1
18 J7053660A TENSION BKT[J7053660A] 2
19 J6614007A LEAD SCREW[DCM16 + 648.5L] 2
20 J7053781A CV CHIP COVER-R[J7053781A] 1
21 J7053731A CONVEYOR CHIP COVER-R[J7053731A] 1
