NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 EP07-901508 SERVO_FAN_FG_CABLE_ASSY 2 EP07-901508
2 EP06-001076 SERVO CONTROL-DRIVE-MCDLN35SE 2 EP06-900170 / EP06-000389 750W, X Axis
3 EP06-000492 SERVO CONTROL-DRIVE-MBDJT2205-LIQI 2 EP06-900172 / EP06-000445 100W, Width/Swing Axis
4 EP06-000393 SERVO CONTROL-DRIVE-MDDKT5540E 4 EP06-900171 1KW, Y Axis
5 J7251012A WIRING DUCT-5[J7251012A] 1
6 FC09-000879B BRACKET-STEP_DRIVER_BRACKET;SPCC,1.6 1
7 EP06-000390A SERVO CONTROL-DRIVE-STEBRO-SPB-WW-V1.0 2
EP06-000391A SERVO CONTROL-DRIVE-STEBRO-SPB-ST-V1.0 4
8 AM06-000943D ASSY,PCB-AP5_AXIS_IO_BOARD 1 FC09-001716A/ AM06-000943B/ AM06-
000943C
9 J7251007A BOARD COVER[J7251007A] 1
10 AM03-001814C ASSY,BOARD-SAFETY_FROP_REV_3.0 1 AM03-001814A / AM03-001814B
11 J7251015A WIRING DUCT-8[J7251015A] 1
12 FC15-002483A COVER-COVER R AXIS B 1
13 ELECTRIC ASSY DC
J37041002A RELAY_HOLD_DOWN_CLIPS PYC-A1 2
EP18-900016 RELAY[MY2N-D2 24VDC] 1
EP05-901144 RELAY SOCKET [PYF08A] 1
EP18-000127 RELAY,AC-LY2N,220VAC,MIGRATION 1
EP18-000128 ACCESSORY,RELAY-SZX-SLF-08N;SOCKET 1
EP07-000576 BREAKER,CIRCUIT-SH202-C16;MCBs,2P,440V 2
EP07-000731 BREAKER,CIRCUIT-SH203-C16;MCBs,3P,440V 1
EP21-000093 BLOCK,TERMINAL-281-611;DIN,1P,60X8X60MM 3
EP21-000094 BLOCK,TERMINAL-2002-1301;DIN,3P,59.5X33 10
EP21-000095 BLOCK,TERMINAL-2002-1401;DIN,4P,70.0X33 10
EP21-000096 BLOCK,TERMINAL-2002-2201;DIN,4P,70.0X52 2
EP21-000118 BLOCK,TERMINAL-281-511 2
EP21-000120 BLOCK,TERMINAL-281-656 2
Page
HANWHA TECHWIN
100
SM471
PLUS
Electric Device Ass’y (1/4)
11
12
13
16
15
14
2
1
9
10
9
7
4
3
8
5
6
17
