SM411_TRM(Ver12.0_CS16.50) - 第46页
Page HANWHA TECHWIN 34 SM411 Conveyor Ass'y (6/6) 3 4 4 4 5 1 2 1 5 2
Page
HANWHA TECHWIN
33
SM411
Conveyor Ass'y (5/6)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
Page
HANWHA TECHWIN
34
SM411
Conveyor Ass'y (6/6)
3
4
4
4
5
1
2
1
5
2
Page
HANWHA TECHWIN
35
SM411
Conveyor Ass'y (6/6)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J72531005C DUMP_BOX 4 J72531005A/ J72531005B
2 FC09-004094A DUMP_BOX_SUPPORT_1 2 J70531059A/ FC29-002694C AIR SHOWER OPTION
3 HP09-900109 REGULATOR 2 HP09-900110
4 HP14-900040 SOLENOID_VALVE 2
5 EP20-900101 SWITCH_CLAMP EP20-900101 4 AIR SHOWER OPTION
6 FC09-004095A DUMP_SUPPORT_2 2
