9 Maintenance SIPLACE 80S-20/F4/F5 User Manual
9.1 Overview 05/99 Issue from Software Version SR.405.xx
9 - 8
9.1.5 Tools and Consumables Required for Maintaining the SIPLACE
80S-20, 80F
4
, and 80F
5
Placement Machines
The lists of materials stated below indicate all of the tools, equipment and consumables required for maintain-
ing the SIPLACE 80S-20/F
4
/F
5
placement machines.
NOTE
• Always use soft, clean and lint-free cloths for cleaning work.
• Do not use any solvents, use ethyl alcohol only!
• Apply all lubricants and all oil only sparingly and only where required.
9.1.5.1 List of Materials Required for Maintenance of the SIPLACE 80S-20 Place-
ment Machines
For maintenance you will require the tools and equipment listed below:
Tools, Equipment From item number
Brush, soft and grease-free
Brush with short bristles
Collecting pan
Grease gun 02101695-01
Hexagon socket screw key, set of
Laboratory gloves, white
Marker pen, permanent
Metal drill, 1.2 mm dia.
Metal drill, 1.4 mm dia.
Oilstone
Plastic brush, 6 mm dia. 00325929-01
Standard screwdrivers, set of
Tweezers
Vacuum cleaner
Work gloves, strong
Tab. 9.1.1 Tools and equipment required for maintenance of the SIPLACE 80S-20 placement machine
SIPLACE 80S-20/F4/F5 User Manual 9 Maintenance
05/99 Issue from Software Version SR.405.xx 9.1 Overview
9 - 9
9.1.5.2 List of Materials Required for Maintenance of the
SIPLACE 80F
4
/F
5
Placement Machines
The lists of materials required for maintenance of the SIPLACE 80S-20 placement machine also apply to the
SIPLACE 80SF
4
/F
5
.
In addition you will need:
Consumables From item number
Cloth, lint-free
Ethyl alcohol
Viledon filter mat 225 x 362 00304048-01
ISOFLEX TOPAS NCA 52 00328369-01
Rust-prevention spray WD40, 400 ml 00325833-01
Segment maintenance cloth 00315253-01
Soapy water
Staburags N12 lubrication grease 02100611-01
Tissue
Unisilkon L250L 00310259-01
Urethyn E/M2, grease cartridge 02101696-01
Watchmaker’s oil, 5 ml 02100393-01
Tab. 9.1.2 Consumables required for maintenance of the SIPLACE 80S-20 placement machine
Tools and equipment From item number
Change-over table lifting cart HS/SP/WPW/SIPLACE 80 00123141-01
Nozzle removal tool 00311448-01
Tab. 9.1.3 Additional tools and equipment required for maintenance of the SIPLACE 80F
4
/F
5
placement machine
Consumables
Lens cleaning cloth, moisture-sealed pack
Lens cleaning tissue (from Kodak, for example)
Talcum
Tab. 9.1.4 Additional consumables required for maintenance of the SIPLACE 80F
4
/F
5
placement machine
