PREVENTIVE MAINTENANCE
Maintenance Plan
Chapter Issue 2, July 16 Maintenance Manual 1.7
Accuracy Check The accuracy check should be performed after doing 10 cycles unmeasured,
allowing the machine to settle. Month 1 and Month 7 are 100 cycles, all other
months are 30 cycles as shown in the table below.
Pre and Post print measurements are taken to record the accuracy of the
alignment in CPK values and the front and rear squeegee pressures.
SPC Results Where the QC Calc for Windows program is installed, SPC data capture can
graphically show critical alignment and squeegee pressure accuracy. The
graphs in their visual form are often useful in determining the optimum mainte-
nance plan.
NOTE
Customers may opt to use the collected data in their own management system,
ASM cannot provide support for this.
Examining the
Collected Data
In addition to examining the SPC data which is displayed graphically in the QC
Calc for Windows program, engineers can extract information about machine
performance from other sources.
The SPC data collected on the machine is stored in E:\config\readings.dek.
Information can be displayed in a text editor and specific data can be examined
eg, events between dates or a specific word or phrase.
Each occurrence of an error for example, can be examined to see if the rate at
which it has occurred has increased (is it a random occurrence or an increasing
trend?).
Authorization At the end of each monthly task a Summary/Remarks form is provided to allow
the engineer to make comments or express observations. The engineer must
sign off and date the form on Page 1 so that there is a record that the schedule
has been completed.
Month Pre X Pre Y Pre Theta Post X Post Y Post Theta Front
Squeegee
Rear
Squeegee
1 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles
2 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
3 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
4 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
5 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
6 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
7
100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles 100 Cycles
8 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
9 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
10 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
11 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
12 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles 30 Cycles
PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
1.8 Maintenance Manual Chapter Issue 2, July 16
MONTHLY MAINTENANCE
Each month the following tables are filled in prior to carrying out any equipment
checks. Prior to running the thirty test cycles required for the table below, run
ten cycles to allow the machine to settle.
SPC Alignment
Check
Follow details in the Accuracy Check section previously described in this
chapter. Record details for each month.
Machine Cycle
Count
Record the machine cycle count for each month.
Month Pre X Pre Y Pre Theta Post X Post Y Post Theta Front
Squeegee
Rear
Squeegee
1
2
3
4
5
6
7
8
9
10
11
12
Month Insert the Cycle Count Number of cycles between visits
1
2-
3-
4-
5-
6-
7-
8-
9-
10 -
11 -
12 -
PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
Chapter Issue 2, July 16 Maintenance Manual 1.9
Maintenance Procedure for Month 1
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS MAY
CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. WHEN USING CLEANING
WIPES AND CLEANING SOLUTIONS THE MANUFACTURERS’ SAFETY DATA
SHEETS MUST BE STRICTLY ADHERED TO.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. EYE PROTECTION MUST BE WORN.
SPC Alignment
Check and Machine
Cycle Count
Fill out details: SPC Alignment Check and Machine Cycle Count on Page 8.
Software
Monthly Maintenance
Before commencing with the Monthly Maintenance, ensure the Daily Mainte-
nance has been completed.
Software Check Record Tick
Check the date and time settings.
Check the software loaded and options.
Check the software version is the latest issue.
View Event Log Tick
Check for initialisation errors.
Check for stencil position errors (31210, 31211, 31212).
Check for camera errors (31207, 31208).
Adjustable Stencil Mount (ASM) Tick
Remove any debris and clean the ASM assembly. See Page 62.
Remove any debris and clean the pulley assemblies. See Page 62.
