PREVENTIVE MAINTENANCE MONTHLY MAINTENANCE Chapter Issue 2, July 16 Maintenance Manual 1.15 Summary/Remarks If used, enter ‘Y es’ in the Summary/Remarks column on Page 1
PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
1.14 Maintenance Manual Chapter Issue 2, July 16
Monthly Hardware Check
Machine Safety Tick
Check operation of the cover interlock.
Check operation of the Emergency Stop button.
Examine the condition of the mains input lead.
Check all earth leads and bonding points are connected.
Toggle all beacon lights.
Pneumatics Tick
Check air pressure switch is set to 3 bar.
Check the air inlet regulator is set to 5 bar.
Check pipes for air leaks.
Check and empty the air line water trap.
Check and empty the air line water trap on the Grid-Lok Control Unit
Stencil Change Tick
Remove and clean the auto drip tray. See Page 65.
Fully extend the auto drip tray telescopic plungers and clean. See Page 65.
Clean the stencil stop/stencil actuator arm lever.
Refit the auto drip tray and check operation of the stencil change mechanism.
Chase Tick
Inspect the condition of wiring/pneumatic connections.
Check operation of the chase clamps.
Clean and lubricate with light oil, the omni track bearings and the underside of the track plates. See Page 60.
Clean the left and right stencil at centre optos (ASM only). See Page 62.
Clean the stencil at centre sensor (Machined C Chase and AWSM only). See Page 61/Page 63.
Remove any debris and clean the stencil guide strips. See Page 61/Page 62.
Remove any debris and clean the stencil guide leaf springs. See Page 61/Page 62/Page 63.
Remove any debris and clean the stencil support plates. See Page 61/Page 62/Page 63.
Remove any debris and clean the stencil clamp lever actuator bar, lubricate with light grease (AWSM only). See
Page 63.
Ensure the connection between the stencil clamp lever actuator bar and the stencil clamp lever is lubricated with
light grease (AWSM only). See Page 63.
Check ASM flap clamp cord tension (cord stretch may cause it to wrap around the pulley shaft). See Page 62.
Check operation of the ASM/AWSM. See Page 62/Page 63.
PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
Chapter Issue 2, July 16 Maintenance Manual 1.15
Summary/Remarks
If used, enter ‘Yes’ in the Summary/Remarks column on Page 1
PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
1.16 Maintenance Manual Chapter Issue 2, July 16
Maintenance Procedure for Month 3
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS MAY
CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. WHEN USING CLEANING
WIPES AND CLEANING SOLUTIONS THE MANUFACTURERS’ SAFETY DATA
SHEETS MUST BE STRICTLY ADHERED TO.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. EYE PROTECTION MUST BE WORN.
SPC Alignment
Check and Machine
Cycle Count
Fill out details: SPC Alignment Check and Machine Cycle Count on Page 8.
Software
Monthly Maintenance
Before commencing with the Monthly Maintenance, ensure the Daily Mainte-
nance has been completed.
Software Check Record Tick
Check the date and time settings.
Check the software loaded and options.
Check the software version is the latest issue.
View Event Log Tick
Check for initialisation errors.
Check for stencil position errors (31210, 31211, 31212).
Check for camera errors (31207, 31208).
Adjustable Stencil Mount (ASM) Tick
Remove any debris and clean the ASM assembly. See Page 62.
Remove any debris and clean the pulley assemblies. See Page 62.
