PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
1.52 Maintenance Manual Chapter Issue 2, July 16
Monthly Hardware Check
Machine Safety Tick
Check operation of the cover interlock.
Check operation of the Emergency Stop button.
Examine the condition of the mains input lead.
Check all earth leads and bonding points are connected.
Toggle all beacon lights.
Pneumatics Tick
Check air pressure switch is set to 3 bar.
Check the air inlet regulator is set to 5 bar.
Check pipes for air leaks.
Check and empty the air line water trap.
Check and empty the air line water trap on the Grid-Lok Control Unit
Rising Table Tick
Inspect the condition of the rising table drive belt. See Page 53 or Page 54.
Check for correct operation of the table brake.
Cycle the table, ensuring smooth running, no looms fouled.
Check the home setting.
Check the vision height of the table.
Check the print height of the table.
Vacuum Filtration Unit Tick
VF35i, replace the pre-filter and the carbon filter. See Chapter 2.
VF25, replace the pre-filter and the carbon filter. See Chapter 2.
VF10, replace the white HDPE foam filter. See Chapter 2.
Summary/Remarks
If used, enter ‘Yes’ in the Summary/Remarks column on Page 1
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 2, July 16 Maintenance Manual 1.53
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Rising Table Style 1
Figure 1-1 View on Rear of Rising Table
Item Description Item Description
1 Manual Tooling Plate 4 Rising Table Drive Belt
2 Transport Rail Drive Belt 5 Vertical Linear Bearing Guide (in 2 positions)
3 Rising Table Ballscrew
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
1.54 Maintenance Manual Chapter Issue 2, July 16
Rising Table Style 2
Figure 1-2 View on Rear of Rising Table
Item Description Item Description
1 Manual Tooling Plate 3 Vertical Linear Bearing Guide (in 2 positions)
2 Rising Table Drive Belt 4 Rising Table Ballscrew
