PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 2, July 16 Maintenance Manual 1.69
Under Stencil Cleaner
Figure 1-17 View on Left Side of USC
Item Description Item Description
1 USC Magnet (in 2 positions) 3 USC Linear Bearing Block (in 2 positions)
2 USC Home Sensor 4 Camera Y Linear Bearing Guide Rail (in 2 positions)
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
1.70 Maintenance Manual Chapter Issue 2, July 16
External Solvent Tank
Figure 1-18 View of External Solvent Tank
Item Description Item Description
1 Solvent Container 3 External Solvent Tank
2 Solvent Container Housing
1
2
3
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 2, July 16 Maintenance Manual 1.71
Internal Solvent Tank
Figure 1-19 View on Rear Left Side of Style 5 machine
Item Description Item Description
1 Solvent Container 3 Solvent Drain Tap
2 Solvent Drain Hose
1
2
3
