8 Appendix
On the following pages you'll find programming charts.
GF-type name
SIPLACE VISION
possible version
/Symetries Body Terminal (PIN) Group optical recognition Convertion/ specialities
additionally f.
ICOS
Unleaded GF's
Symetries should tell
you as a user which
comp.side have to be
identical.
'reduce optical width' is a
menu for the GF-re-export to
the LC; nowhere else used.
what should be
known from
ICOS-system
BareDie
axis symetrical to both
comp. coordinate axes Rectangular None None
Position measurment /
Inspection by body dimension
(FaceDown inspection since
702/SV4.0.1)
MFU (MCC)-ceramic comp. flat
illumination spec. set. PDC's from
ICOS would be BareDies - GF's
have to be re-programmed and re-
classified if PIN'S are there !
PDC definition
define body
dim.measureme
nt only.
Chip
axis symetrical to both
comp. coordinate axes /
PIN dim in both groups
identical.
Rectangular
Wraparounds:
with PIN width equal to
body width set. The PIN's
are inside the body
2 groups: group offset
automatically set by body
length
Position measurement /
Inspection by body dimens.
comp. height for comp. sen-
sor in pickup placement pos.
FaceDown & since 702
(SV4.01) with lead length
special form: body round terminal
rectanguplar
program Z-height for profile and
comp. sensor.
at the begin
CHIPs defined
without PIN's ->
'virtual'-
BareDies
Melf
axis symetrical to both
comp. coordinate axes /
PIN dim.in 2 gr. identical
/
horizontal cyl. define
body width like
measured without limit.
Horizontal
cylinder / this
define disabled
Pickup pos.
Corr.
comp.edge terminal
bended round
Wraparounds
2 groups: group offset
automatically set by body
length
Position measurement /
Inspection by body dimension
comp. height for comp. sensor
in pickup placement pos.
The MELF is so illuminated that
comp.width is recognized with
100% programmed width. Pickup
position correction OFF. Special
form: Terminal round body
squared
From horizontal
cylinder (LC red.
optical width)
ICOS define
each comp.
width is correct.
Moulded
(min. axis symetrical on
one comp. coordinate
axes) / PIN dim. In both
gr. identical programmed Rectangular
Wraparounds: PIN width
is smaller than the body
width
PIN-length is shorter than
PIN width
real PINs may have
different length
2 groups: group offset
automatically set by body
length
Position measurment /
Inspection by body dimension
At dark body by Length &
Pinwidth. (FaceDown since
702/SV4.0.1) For a
Wraparound PIN could the
feature 'dark' be selected.
different colored bodies are
recognizable with one GF-
description! Note in comment
witch GF is used for X-machine.
Inspection mode to switch off!
if the PINs are
smaller than the
body is the body
dim. NOT
checked.
Leaded GF's
no notches allowed on
un- / leaded GF allowed
all gullwings could be tested
on Pin width s. 702 (SV4.01)
ECV
Electrolyt
capacitor
vertical
is 2x axis symetrical /
both PIN dim. Identical. Vertical cylinder
Gullwings: prog. Contact
length longer than 1/2 PIN
-
length align body better.
PIN-length longer than PIN
width
2 identical groups on
opposite comp. sides
Position measurement /
Inspection PIN inspection.
Body possibly turned if PIN
sideway out of position.
after autom. convertion is comp. a
Moulded type. For GF-type;
body;PIN and so on is a manual
re-program. required!
body shape vert.
cylinder is
unknown.
SOT
Small Outline
Transistor
/ SOD Rectangular
Gullwings: could have 2
different dimensions.
minimal 2 different groups
on opposite component
sides.
Same PIN length => same
group offsets
Position measurement /
Inspection PIN inspection
(FaceDown since
702/SV4.0.1)
Attention different SOT23 Norms!.
Coplan make no sense on
SOT23!
body print color as a Programming code (if poss. at customer):
Blue 'Require separate group description' for SIPLACE Vision
Red defect or purple 'Teaching required'
Orange reprogrammed or corrected in body or ICOS-group description.
