On the following pages you'll find programming charts.
GF-type name
SIPLACE VISION
possible version
/Symetries Body Terminal (PIN) Group optical recognition Convertion/ specialities
additionally f.
ICOS
Unleaded GF's
Symetries should tell
you as a user which
comp.side have to be
identical.
'reduce optical width' is a
menu for the GF-re-export to
the LC; nowhere else used.
what should be
known from
ICOS-system
BareDie
axis symetrical to both
comp. coordinate axes Rectangular None None
Position measurment /
Inspection by body dimension
(FaceDown inspection since
702/SV4.0.1)
MFU (MCC)-ceramic comp. flat
illumination spec. set. PDC's from
ICOS would be BareDies - GF's
have to be re-programmed and re-
classified if PIN'S are there !
PDC definition
define body
dim.measureme
nt only.
Chip
axis symetrical to both
comp. coordinate axes /
PIN dim in both groups
identical.
Rectangular
Wraparounds:
with PIN width equal to
body width set. The PIN's
are inside the body
2 groups: group offset
automatically set by body
length
Position measurement /
Inspection by body dimens.
comp. height for comp. sen-
sor in pickup placement pos.
FaceDown & since 702
(SV4.01) with lead length
special form: body round terminal
rectanguplar
program Z-height for profile and
comp. sensor.
at the begin
CHIPs defined
without PIN's ->
'virtual'-
BareDies
Melf
axis symetrical to both
comp. coordinate axes /
PIN dim.in 2 gr. identical
/
horizontal cyl. define
body width like
measured without limit.
Horizontal
cylinder / this
define disabled
Pickup pos.
Corr.
comp.edge terminal
bended round
Wraparounds
2 groups: group offset
automatically set by body
length
Position measurement /
Inspection by body dimension
comp. height for comp. sensor
in pickup placement pos.
The MELF is so illuminated that
comp.width is recognized with
100% programmed width. Pickup
position correction OFF. Special
form: Terminal round body
squared
From horizontal
cylinder (LC red.
optical width)
ICOS define
each comp.
width is correct.
Moulded
(min. axis symetrical on
one comp. coordinate
axes) / PIN dim. In both
gr. identical programmed Rectangular
Wraparounds: PIN width
is smaller than the body
width
PIN-length is shorter than
PIN width
real PINs may have
different length
2 groups: group offset
automatically set by body
length
Position measurment /
Inspection by body dimension
At dark body by Length &
Pinwidth. (FaceDown since
702/SV4.0.1) For a
Wraparound PIN could the
feature 'dark' be selected.
different colored bodies are
recognizable with one GF-
description! Note in comment
witch GF is used for X-machine.
Inspection mode to switch off!
if the PINs are
smaller than the
body is the body
dim. NOT
checked.
Leaded GF's
no notches allowed on
un- / leaded GF allowed
all gullwings could be tested
on Pin width s. 702 (SV4.01)
ECV
Electrolyt
capacitor
vertical
is 2x axis symetrical /
both PIN dim. Identical. Vertical cylinder
Gullwings: prog. Contact
length longer than 1/2 PIN
-
length align body better.
PIN-length longer than PIN
width
2 identical groups on
opposite comp. sides
Position measurement /
Inspection PIN inspection.
Body possibly turned if PIN
sideway out of position.
after autom. convertion is comp. a
Moulded type. For GF-type;
body;PIN and so on is a manual
re-program. required!
body shape vert.
cylinder is
unknown.
SOT
Small Outline
Transistor
/ SOD Rectangular
Gullwings: could have 2
different dimensions.
minimal 2 different groups
on opposite component
sides.
Same PIN length => same
group offsets
Position measurement /
Inspection PIN inspection
(FaceDown since
702/SV4.0.1)
Attention different SOT23 Norms!.
Coplan make no sense on
SOT23!
body print color as a Programming code (if poss. at customer):
Blue 'Require separate group description' for SIPLACE Vision
Red defect or purple 'Teaching required'
Orange reprogrammed or corrected in body or ICOS-group description.
Edition 3.0 17.10.2008 GF kurzref_A4_DE.xls GF prog.ref. landsc Siemens Ind. Sec EA1 SC E
GF-type name
SIPLACE VISION
possible version
/Symetries Body Terminal (PIN) Group optical recognition Convertion/ specialities
additionally f.
ICOS
SOxx
S
mall
O
utline xx Rectangular
only one kind of Gullwing-
terminal. PIN width is
always as wide as contact
width!
min. 2 ident ical groups:
on opposite comp. sides
different PIN nr./ X-group
offset allowed.
Position measurement /
Inspection PIN inspection
(FaceDown & Colinearity since
702/SV4.0.1)
SO 2 could be classified in SOT
too.
QFP Q
uad
F
lat Pack &
'bumpered' QFP Rectangular
only one kind of Gullwing-
terminal. PIN width is
always as wide as contact
width!
min. 4 groups. -with diff.
PIN nr.- on opposite comp.
side. More than 1 group
per side allowed
Position measurement /
Inspection PIN inspection
(FaceDown & Colinearity since
702/SV4.0.1)
Sockets could be classified as a
QFP too.
Ortogonality is
checked. The
PIN-row center
of opposite
sides may
deviate about --
-->
DPACK
Dual
Pack
*
Rectangular
Gullwings: wide PIN min. 2
times as wide as normal
PIN width. Could be
programmed as a
Wraparound too.
Placem.offset for correct
prog. 1/2x PIN length diff.
min. 2 groups: wide PIN as
a single PIN on one comp.
side. Different PIN
length=> different group
offsets (New program.
Body drawing correct=>
placement pos. to adopt
*)
Position measurement /
Inspection PIN inspection
(FaceDown since
702/SV4.0.1)
possibly (according
programming quality) crazy body
drawings visible.
Careful manual re-programming
required
very often is the
heat sink not
described ->
angle recog.
Reliability
limited.
SOJ
S
mall
o
utline
J
-Lead Rectangular
only one kind of
J-Leads. PIN width
is as wide as
contact width
min. 2 groups -with diff.
PIN nr.- on opposite comp.
Side. More than 2 groups
allowed !check?
Position measurement /
Inspection PIN inspection
PLCC
P
lastic
L
eaded
C
hip Carrier Rectangular
only one kind of J-Leads.
Set J-Leads if such a PIN
is to recognize in
cameral!
min. 2 groups -with diff.
PIN nr.- on opposite comp.
Side. More than 4 groups
allowed
Position measurement /
Inspection PIN inspection
---->
ortogon. …..
mm.
This is valid for
4 sided GF's!!
GF's with round terminals
BGA
B
all Grid Array Rectangular
one kind of hemispherical
terminal (Ball)
one or more groups with
skipped programmed
terminals
Position measurement by
max.20 terminals (Ball)
Inspection presence and
position check.
with special 'Ball filter' and
correct illumination missing
'Balls' recognized!
CCGA's were in ICOS defined for
BGA's!
Shields definded with drill holes
are in ICOS defined for BGA -
taught for 'black Balls'
Inspection mode to switch off!
CCGA
C
eramic
C
olumn Grid
A
rray Rectangular
one kind of column
shaped terminal (column)
one or more groups with
skipped programmed
terminals
Position measurement by
max.20 terminals (Ball)
Inspection presence and
position check. different filter
and illum. than BGA
New kind of component which
was in ICOS a BGA. Manual to re
classify. Inspection mode to
switch off!
centered like a
BGA.
