Camera type for machine with SV in Siplace pro Description / Head / Machine Picture Field of View FOV/ resolution Component size min. feature size Illumination -- SST 24 PCB-camera multicolor SIPLACE Vision for X-ma. 494…
Edition 3.1 07.02.2008 _Kamera prog übers_ku_cu.xls Cam SIP Pro e Siemens A+D EA1 SC E
Camera type for
machine with SV
in Siplace pro
Description /
Head / Machine Picture
Field of View
FOV/
resolution
Component
size min. feature size Illumination
--
SST 24
PCB-camera
multicolor
SIPLACE Vision
for X-ma.
494 x494
pixel
5,8x 5,8 mm
~12µm/Pixel
fiducial size 3x3
mm
depend on fiducial type
down to min. 0,25 mm
edge length
White, white
difuse,IR, IR difuse
blue
--
SST 34
PCB-camera
SIPLACE Vision
Standard for HS
-
D..-machine. unit height small. SST24
494 x494
pixel
5,8x 5,8 mm
~12µm/Pixel
fiducial size 3x3
mm
depend on fiducial type
down to min. 0,25 mm
edge length Red, blue
C&P20
CAMERA X (23)
8,2x8,2
SST23
BE-Kamera dig.
C&P20 Head
Standard at
C&P20 head of
the X-Machine
1200 x1200
pixel
8,2 x 8,2 mm
17µm/Pixel 6 x 6 mm
0.4 x 0.2mm (01005)
lead pitch 0.3mm /
lead width 0.1mm /
ball pitch 0.4mm /
ball-diam. 0.2mm
Red LED's in 5
levels
RV CAMERA X
(38) 24,2x24,2
SST38
BE-Kamera dig.
C&P12 head
very high
resolution cam.
at C&P12 head
of the X-
Machine (cam.
amplif. iX20) recognizeable by sticker
1200 x1200
pixel
20,5 x 20,5
mm
~17µm/Pixel 16 x 16 mm
0.4 x 0.2mm (01005)
lead pitch 0.1mm /
lead width 0.1mm /
ball pitch 0.25mm /
ball-diam. 0.14mm
Red LED's in 4
levels
RV CAMERA X
(28) 24,2x24,2
SST28
BE-Kamera dig.
C&P12 head
Standard at
C&P12 head of
the X-Machine
(cam.amplfier
iX03)
494 x494
pixel
24 x 24 mm
~50µm/Pixel 18,7 x 18,7 mm
0.5 x 0.5mm (0402)
lead pitch 0.5mm /
lead width 0.2mm /
ball pitch 0.45mm /
ball-diam. 0.25mm
Red LED's in 4
levels
RV CAMERA X
(29) 32x32
SST29
Comp.camera
dig. C&P6 (high
resolution C&P
12) recognizable
at the higher
camera ampl.
Standard at
C&P6 head
/option at
C&P12 head
1200 x1200
pixel
32 x 32 mm
~27µm/Pixel 27 x27 mm
indep. from head type
com.size smal. 18mm
0.6 x 0.3mm (0201 only
C&P12)
lead pitch 0.3mm /
lead width 0.15mm /
ball pitch 0.25m /
ball-diam. 0.14mm
com.size larg. 18mm
~lead pitch 0.4mm /
~lead width 0.2mm /
ball pitch 0.35m /
ball-diam. 0.2mm
Red LED's in 4
levels
comp. sensors for height recognition -NOT Vision system controlled!!
Option only
at C&P 12
head of
HS/HF/S27/X
limited comp.
height at fitting
nozzle
permanent IR-beam
mounted between
star pos. 10-11
Standard for
C&P20 head
at the X-
Machine
for all comp.'s
placeable with
C&P 20 head
permanent red
LASER-beam
mounted at star
pos. 1( pick/place)
RV Cam COMP SENSOR
comp. sensor C&P12 head
C&P 20 Cam COMP SENSOR
comp. sensor C&P20 head
Edition 3.1 07.02.2008 _Kamera prog übers_ku_cu.xls Cam SIP Pro e Siemens A+D EA1 SC E
Camera type for
machine with SV
in Siplace pro
Description /
Head / Machine Picture
Field of View
FOV/
resolution
Component
size min. feature size Illumination
FC CAMERA
X(25) FOV
19x19
SST25
FC-camera dig.
TWIN head
add, option for
TWIN head
at the X-/D3
Ma. & P&P
module at D1
1200 x1200
pixel
19,4x19,4mm
16µm/Pixel 16 x 16mm
0.2 x 0.1mm (01005)
lead pitch 0.25mm /
lead width 0.1mm /
ball pitch 0.14mm /
ball-diam. 0.08mm
Red LED's in 6
levels
IC CAMERA X
(33) 65x50
SST33
IC-camera dig.
TWIN head
Standard for
TWIN at the X-
/D3-Ma.
(Option for D1)
1200 x1200
pixel
65 x 50mm
~42µm/Pixel
dual comp.
55x45mm
(69x10)
single, 85x85mm
(125x10).
with restriction
200x125mm
0.5 x 0.5mm (0402)
lead pitch 0.3mm /
lead width 0.15mm /
ball pitch 0.45m /
ball-diam. 0.25mm
Red LED's in 6
levels
IC CAMERA (36)
50x38
SST36
IC-camera dig.
TWIN head
Standard for
TWIN at D1-ma.
View from
outside like
SST33 for
difference see
sticker!
640 x480
pixel
50 x 38mm
~80µm/Pixel
32x32mm single
measurment
lead pitch 0.4mm /
lead width 0.24mm /
ball pitch 0.56m /
ball-diam. 0.32mm
Red LED's in 6
levels
Coplanarity 3D-
module SST37
X2 / X3 2nd
placement area
with TWIN
(Inspection
time BGA 256
(1.27mm
pitch)
<250ms)
50 x 50mm
(125x20mm
lead pitch 0.5mm /
lead width 0.3mm /
ball pitch 0.8m /
ball-diam. 0.4mm
a Red LASER light
line sensor
measuring the
height deviation of
3 D-imensional
structures like
BGA's
PP COP 17 ILD
SST17
Coplan ILD 2000
(controlled with
SC.)D1 machine
min. Pitch
0,4mm
Stationary comp. cameras SIPLACE Vision system controlled. Used for TWINhead or P&P-module
