I･pulse F1 Series F1-16 (H type) P 8 No. Code No. Parts Name Q'ty Parts No. ※1 LG4-M5A90-020 REEL PLATE ASSY 1 AS1-A12-8180-F ※1 LG4-M4A9D-001 TENSION LEVER ASSY 1 AS-A12-8181-E LG4-M4A91-012 REEL PLATE 1 FTA-A12-81…
I･pulse F1 Series
F1-16 (H type)
P 7
No. Code No. Parts Name Q'ty Parts No.
1 LG4-M4AA1-003
CONTROL BOARD 1
FTA-A12-8151-FCB
2
LG4-M1A6R-010
CONTROL BOARD COLLAR
3
FTA-A08-8152-B
3
LG4-M1A6S-001 CONTROL BOARD COVER
1
FTA-A08-8153ｰB
4 K87-M111W-000 SCREW,PAN HEAD+ 3
3MC-5-P
5
K87-M111N-000
SCREW,PAN HEAD+ 3
3MC-3-P
※1 6
LG4-M5AC1-000
SERIAL NO. STICKER 1
FTA-A16-8150-SNS
7 KW1-M11AA-000 ROHS STICKER 1
※1…F1-16-007605H～
I･pulse F1 Series
F1-16 (H type)
P 8
No. Code No. Parts Name Q'ty Parts No.
※1
LG4-M5A90-020 REEL PLATE ASSY
1
AS1-A12-8180-F
※1
LG4-M4A9D-001 TENSION LEVER ASSY
1
AS-A12-8181-E
LG4-M4A91-012 REEL PLATE
1
FTA-A12-8180-E
LG4-M4A91-020 REEL PLATE
1
FTA-A12-8180-F
LG4-M4A9A-002 TENSION LEVER
1
FTA-A12-8181-E
LG4-M4A9A-003 TENSION LEVER
1
FTA-A12-8181-F
※1
3 LG4-M4A9C-001 GUIDE ARM
1 FTA-A12-8181-E1
4 LG4-M4A92-011 TENSION AXIS
1
FTA-A12-8182-C
5 LG4-M4A9B-002 COIL SPRING
1 FTA-A12-8183-D
LG4-M5A93-010 REEL AXIS
1 FTA-A16-8185-C
LG4-M5A93-020 REEL AXIS
1 FTA-A16-8185-D
7
LG4-M4ADE-000
SCREW,FLAT HEAD+ 3 3MK-7-P
8 K87-M55BN-000 SCREW,FLAT HEAD+ 1 3MK-8-P
9 K87-M111U-000 SCREW FLANGE NUT 3 3MH-FS
10
LG4-M4AD4-000 CIRCLIP E
1 E.50
※1 11
LG4-M4AD5-000 FLAT RIVET
2
2×4-2.5-BS
※1
12
LG4 M4ADH 000
SCREW FLAT HEAD+
1
4MK 12 P
6※1
※1 1
※1 2
※
112
LG4-M4ADH-000
SCREW,FLAT HEAD+ 1 4MK-12-P
13
14
15
16
17
18
19
20
21
22
23
24
25
※1…F1-16-006345H～
MODEL ： F1-24 (E_type)
CODE No. ： LG4-M6A00-061
Serial No.
F1-24-003471E～
