SIPLACE Pro 17.0 (R19-2) / Installation Manual 11/2019 Edition 19 If you are installing a local dat abase, the SQL Server Logi n dialog is displayed. In this dialog you enter the information required to c onnect to the S…

SIPLACE Pro 17.0 (R19-2) / Installation Manual 11/2019 Edition

NOTICE

If you perform an upgrade installation using an older version of Support Media, the

password for the SiplaceAdmin user might be an older one that is not known by the

setup. In this case, you will get a login error message and have to enter the correct

password manually.

If you perform a new installation using a current Support Media and did not configure a

custom password, the password for the SiplaceAdmin user will be the default password.

In this case you do not have to enter the password for the account in this step – the

setup wizard will try to use the default password if you do not enter a different one.

In the next dialog, the SIPLACE Pro access rights (SIPLACE Pro Security) can be enabled.

For new installations and upgrades, the Enable Access rights option is disabled by default. This

means there is no restriction of access rights on stored objects.

We recommend that you leave this option disabled until you have created Users, Groups and set

Privileges & Permissions in SIPLACE Pro Desk. After that, you may activate the Enable Access

Rights option by modifying the Security On/Off option in the Settings tab of SIPLACE Pro Desk.

Figure 6-8: Enabling / disabling SIPLACE Pro access rights

► Click the Next button.

NOTICE

► To reconfigure your SIPLACE Pro installation, run the setup again after installation

and select Modify. Please refer to chapter 8.

SIPLACE Pro 17.0 (R19-2) / Installation Manual 11/2019 Edition

If you are installing a local database, the SQL Server Login dialog is displayed. In this dialog you

enter the information required to connect to the SQL Server and database.

If the check results in error messages, these messages will be displayed, and the setup cannot

continue with this database. Only after selecting another database server or after restoring the

database in an error-free state, setup can continue.

Figure 6-9: Selecting database server and authentication method

► Select the appropriate database instance for the listed database.

► Select the desired authentication mode from the Authentication drop-down menu and enter

the required login parameters:

SQL Server Authentication

► Enter the SQL login name and the corresponding password.

The SQL Server performs the authentication.

Windows Authentication (current user)

The currently logged in user name is automatically applied.

The operating system or, if present, the domain controller performs the authentication.

Windows Authentication

► Enter the user name and the corresponding password that you want to use for your login.

The operating system or, if present, the domain controller performs the authentication.

NOTICE

SQL Server role "sysadmin"

The given login must have the "sysadmin" SQL server role, regardless of the

Authentication in which you log in.

► If you want to specify further SQL related settings different from the default settings, select the

Show dialogs to change the default database settings option. Please refer to section 6.2.3.

► In default case, click the Next button.

SIPLACE Pro 17.0 (R19-2) / Installation Manual 11/2019 Edition

The setup will validate the connection to the given database instance and only continue, if it is

valid.

NOTICE

If you installed the SQL server using a current Support Media and did not configure a

custom password, the password for the sa user will be the default password. In this case

you do not have to enter the password for the account in this step – the setup wizard will

try to use the default password for connection to the database if you do not enter a

different one.

However, if you have installed the SQL Server using an older version of Support Media,

the password for the sa user of your SQL installation might be an older one that is not

known by the setup. In this case, you will get a login error message and have to enter

the correct password manually.

SIPLACE Pro is now ready to be installed. The following dialog is displayed.

Figure 6-10: Checking disk space

Before installing, you can check the available, required and recommended disk space (per drive) to

perform the installation.

► Click the Disk Space button.

The Disk Space Requirements dialog is displayed.
