DEK NeoHorizon 03iX HTC
Machine Standard Configuration
Services
Specification
Voltage
100 Volts to 240 Volts ±10%. Single phase 50/60 Hz
Maximum Current at 115V
15 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
8 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤20 Amps is required to be
fitted in line with the machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
850kg boxed (dependent upon configured options
selected with machine)
690kg unboxed (dependent upon configured options
selected with machine)
Approximate Dimensions
2080mm x 1500mm x 1590mm High
(81.9” x 59” x 62.6”) Boxed
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
Acoustic Noise Level
Less than 70dB 2003/1/EC
10
DEK NeoHorizon 03iX HTC
Machine Productivity Options
Process
Specification
Print Method
Paste Dispenser
Paste Roll Height Monitor
ProFlow® ATx
Stinger
Printing Environment Control
Temperature – Floor Mounted Temperature Control
Module (FM TCM)
Top Mounted Temperature Control Module (TM TCM)
Recommended Stencil Frame
VectorGuard
Adjustable Width Stencil Mount (AWSM)
Frame variants – Fully adjustable to accommodate
frame sizes in the range of 381mm to 736mm
(15” to 29”) by 38mm height.
Image position: Centre/Front/Custom
Under Stencil Cleaning
Typhoon Under Stencil Cleaner, fully programmable
with wet/dry/vacuum wipe with external solvent tank
Specify length (300mm, 400mm, 460mm, 515mm)*
Vacuum Assist for Under Stencil
Cleaning
On board vacuum unit 35 litres/second airflow
On board venturi vacuum unit
Stencil Positioning
Automatic loading incorporating squeegee drip tray
Temperature/Humidity Sensor
Monitoring of the process environment
* If configured with an AWSM, the cleaner chamber size should be matched with the minimum AWSM
width and stencil frame width being used
Handling & Cleaner Options
Specification
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Under Stencil Cleaning
Typhoon Under Stencil Cleaner (620mm, poly blade
insert only)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Singulation
Software & Communications
GEM on TCP/IP
Statistical Process Control
On board, reported via operator interface (QC-CALC)
11
DEK NeoHorizon 03iX HTC
Machine Productivity Options
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® tooling
Substrate Transport
Single piece conveyor with flat belts (heavy boards)
Remote board stop (for use with heavy board option)
Dual Speed Motor (for use with standard rails)
Substrate Fixture
All Purpose Clamping (APC) system*
Snuggers (edge clamping)
Foil-less clamps
* Can only be used with Modular rail system
Vision & Verfication
Specification
HawkEye® 750 Paste on Pad Verification
Enabled
HawkEye® 1700 Paste on Pad
Verification
Enabled (camera included)
HawkEye
HawkEye® Bridging (requires HawkEye® 1700
camera)
Data Capture
Specification
Product Data Capture
Verification & Traceability
ProDEK closed loop
Camera bar code reader
