3-45
AKFEDT-ID
(D02_11)
Comment
Set a comment for each step No.
Alphanumeric characters and symbols can be used.
Up to 32 characters (alphanumerics and marks) can be used.
Note
(a) The automatic operation is not affected by these comments.
(b) The comments can be used to check "Ref. No." printed on the upper
surfaces of PCBs.
(D02_12)
Recog Coord X1 [mm] and Recog Coord Y1 [mm]
Set the coordinates of the fi rst fi ducial mark for the local recognition
mode in each text box.
(D02_13)
Recog Coord X2 [mm] and Recog Coord Y2 [mm]
Set the coordinates of the second fi ducial mark for the local recognition
mode in each text box.
(D02_14)
Fiducial Mark FM1 and Fiducial Mark FM2
Set parameters for "Fiducial Mark FM1" (First Fiducial Mark No.) and
"Fiducial Mark FM2" (Second Fiducial Mark No.) related to the local
recognition mode.
Select the mark Nos. (Mark Codes) specifi ed in the PEC recognition
mark data of the operation data.
0601-002
1.5 Placement Data
3-46
AKFEDT-ID
1.5.3 (D03) Placement Data (O-data)
The set parameters can be used to create a repetitive pattern program.
(D03_01)
O-No.
Shown are the step Nos. of the placement data (O).
These step Nos. are regarded as repetitive pattern Nos.
Parameters must be entered in each line (pattern).
O-No.1
O-No.2
O-No.3
O-No.4
Pattern 4
Pattern 2 Pattern 1
Pattern 3
Fig. 3C33 Example of Repetitive Pattern Program
0601-002
1.5 Placement Data
3-47
AKFEDT-ID
(D03_02)
X [mm] and Y [mm]
Set the coordinates of each pattern origin (O
01
through On) based on the
placement coordinate reference (N
0
).
A pattern origin refers to the reference coordinates of a repetitive
pattern.
The pattern origins (coordinate reference of repetitive patterns) must
be determined, regarding the "Z=theta [deg]" data as "0°" (described
in "D03_03") and located at corners on the same side as the placement
coordinate reference (N
0
).
N
0
:
The center of
is the placement coordinate reference.
O
01
:
Pattern Origin of Pattern 1
O
02
:
Pattern Origin of Pattern 2
O
03
:
Pattern Origin of Pattern 3
O
04
:
Pattern Origin of Pattern 4
O04
O03
O02
O01
X
Y
Placement Coordinate
Reference (N
0)
Component
Pattern 4 Pattern 3
Pattern 2 Pattern 1
Fig. 3C34 Example of Repetitive Patterns
0601-002
1.5 Placement Data
