AKFEDT-ID
[6] [Link ID Tree Display] Button
When pressed, this button displays the link and root IDs that are
arranged side by side in the hierarchical (tree) fi le system.
[7] [New] Button
When pressed, this button opens a new "Component Library" edit
window with default values.
[8] [Open] and [Cancel] Buttons
[Open] Button
When pressed, this button opens the "Component Library" edit window
that corresponds to the selected component ID.
[Cancel] Button
When pressed, this button closes the "Selection of component ID"
window.
[9] [Type Addition] Button
When pressed, the "Type Addition" dialog box opens, enabling the
operator to add a component type.
Reference
Refer to "1.2.1 Type Addition" for the "Type Addition" dialog box.
0601-002
1.1 "Selection of component ID" Window
4-4
AKFEDT-ID
[10] [Current], [Property...], [Delete...], [Copy...], [Rename...],
[Create Link ID], and [Merge...] Buttons
[Current] Button
When pressed, this button displays the component IDs used in the last
pattern program (the last selected program) in "[1] "List of Component
IDs" Pane".
[Property...] Button
When pressed, this button opens the "Property" window that
corresponds to the selected component ID.
Reference
Refer to "1.2.7 Property of Component ID" for the details of the "Property"
window.
[Delete...] Button
When pressed, this button deletes the selected component ID.
[Copy...] Button
When pressed, this button opens the "Copy Component ID" window,
enabling you to make a copy of the selected component ID.
[Rename...] Button
When pressed, this button opens the "Rename" window, enabling you
to change the ID (name) of the selected component.
[Create Link ID] Button
When pressed, this button opens the "Create Link ID" window, enabling
you to create a link ID for the selected component ID.
[Merge...] Button
When pressed, this button opens the "Merge" window, enabling you to
merge the selected component ID.
0601-002
1.1 "Selection of component ID" Window
4-5
AKFEDT-ID
1.2 Basic Operations in "Selection of component ID"
Window
1.2.1 Type Addition
When the [Type Addition] button is pressed, the following "Type Addition"
dialog box opens.
By adding a type, the list of component IDs is displayed after being fi ltered.
[6][3] [4]
[2][1]
[5]
[7]
Fig. 3D2 "Type Addition" Dialog Box
[1] "Type Name" and "Description"
Enter parameters in these text boxes.
[2] "List of Component Types" Pane
Newly created component types are displayed in this pane.
[3] [Add] Button
When this button is pressed, a type entered in the "Type Name" text box
is added as a new type.
[4] [Change] Button
When this button is pressed, a component type is changed to the
contents entered in the "Type Name" and "Description" text boxes.
[5] [Delete] Button
When this button is pressed, the component type selected in "[2]" is
deleted.
0601-002
1.2 Basic Operations in "Selection of component ID" Window
