6-55
AKFEDT-ID
[2] Cmpnt recog camera position correct
Mode
"Correct" or "No Correct" can be selected to determine whether or
not the component recognition camera position should be corrected
periodically.
Note
It is recommended to set "Correct" in normal cases.
Mount counts [times]
Press the icon ( ) to open the "Ten-Key Pad" window and enter
either "0" or "1 to 9999".
0 :
No automatic correction operation is performed for
each number of components to be placed.
1 to 9999 :
Correction is made according to the specifi ed number
of components to be placed.
Note
(a) When "Correct" is set in the "Mode" text box, the corrective actions
take place automatically before the PCB is transferred to the PCB
positioning section and the component recognition operation is
performed.
(b) When the number of components (components to be placed on
a production PCB) per beam is smaller than the set number of
components, the corrective actions do not take place in the middle of
placement operation.
Because the internal counter for interval monitoring is cleared
through the above-described corrective actions (the actions which
take place during PCB positioning), no corrective actions take place
in compliance with the number of components to be placed on several
PCBs.
[3] Feeder message rate
Err counts, # of picks [times]
Set the parameters to show the feeder slot No. (Fdr. No.) of the tape
feeder whose pickup rate has deteriorated during automatic operation.
When the number of picks has reached the specifi ed value, the
parameter in the "Error counts" text box is cleared.
Note
The number of picks and pick-up errors is managed for each individual
feeders but the parameters of "Error counts" and "# of picks" is equally
refl ected on every feeder.
0604-003
2.2 Auto Operation
6-56
AKFEDT-ID
Guide method
"Warning", "Stop (Cycle stop), or "Pause" can be selected to determine
in which mode the machine should be set when the number of pickup
errors has reached the specifi ed error counts before the number of picks
reaches the specifi ed number of picks. When "Warning" is selected, a
warning message is issued as machine information. "Stop (Cycle stop)"
stops the machine after one cycle of operation and "Pause" sets the
machine in the "PAUSE" mode.
Note
When both "Error counts" and "# of picks" are set "0" (zero) or "Error
counts" is set to a number larger than "# of picks", no warning message is
issued.
[4] Nozzle message rate
Error counts and # of picks [times]
Set the parameters to show the nozzle No. whose pickup rate has
deteriorated during automatic operation.
When the number of picks has reached the specifi ed value, the
parameter in the "Error counts" text box is cleared.
Note
The number of picks and pick-up errors is managed for each individual
nozzles but the parameters of "Error counts" and "# of picks" is equally
refl ected on every nozzle.
Guide method
"Warning", "Stop (Cycle stop), or "Pause" can be selected to determine
in which mode the machine should be set when the number of pickup
errors has reached the specifi ed error counts before the number of picks
reaches the specifi ed number of picks. When "Warning" is selected, a
warning message is issued as machine information. "Stop (Cycle stop)"
stops the machine after one cycle of operation and "Pause" sets the
machine in the "PAUSE" mode.
Note
When both "Error counts" and "# of picks" are set "0" (zero) or "Error
counts" is set to a number larger than "# of picks", no warning message is
issued.
[5] Finished product interval
Mode and Interval [pcs.]
(Not Available)
This is one of the progress information messages displayed as machine
information. When "Monitor" is set in the "Mode" text box, the number
of processed products can be monitored every time the number of
processed PCB
’
s reaches the specifi ed parameter in the "Interval" text
box.
Note
When "0" (zero) is set in the "Interval" text box, the number of processed
products cannot be monitored.
0604-003
2.2 Auto Operation
6-57
AKFEDT-ID
[6] Recog image save
Set parameters in the "Object" and "Select" text boxes to analyze the
cause of a recognition error in comparison with the error image on the
monitor.
When "Save" is set in the "Mode" text box, the image which matches
the parameters in the "Object" and "Select" text boxes is stored in
memory of the recognition board.
Mode
Select one of the following options to determine whether or not the
recognized image should be saved.
Not Save :
The recognized image is not saved.
Save [Recog NG] :
The recognized image is saved only
when the recognition results in "NG"
(No Good).
Save [Recog OK] :
The recognized image is saved only
when the recognition results in "OK".
Save [Recog NG/OK] :
The recognized image is saved when
the recognition results in "NG" or
"OK"
.
Object
Select one of the following options as a recognized object to be saved.
Cmpnt & PEC Recog :
Both images captured through
component and PEC recognition
operations are regarded as object
images to be saved.
Cmpnt Recog :
Only the image captured through a
component recognition operation is
regarded as an object image to be
saved.
PEC Recog :
Only the image captured through a PEC
recognition operation is regarded as an
object image to be saved.
0601-002
2.2 Auto Operation
