1-4 AKFEDT -ID 2.2 Composition of Operation Data This data is used to generally manage the pattern program data. This data is composed of the PCB data, the PEC recognition data, the PEC recognition mark data, and the set…
1-3
AKFEDT-ID
2.1.1 Outline of Various Data
The pattern program is composed of the following data.
Operation Data :
This data is used to generally manage
the pattern program data.
Placement Head/Nozzle Data :
This data is used to allocate the
nozzles to the specifi ed positions
(Nozzle Allocation No.) on the heads.
Placement Feeder Location Data :
This data is used to set parameters
which determine a component ID
(type) to be allocated to each feeder
slot No. (Fdr No.).
Placement Data :
The set parameters (designation
of coordinates and direction) are
used for placement of components
allocated in the placement feeder
location data.
2.1.2 Input of Each Data
Enter each data in the pattern program edit window.
Reference
Refer to "2. Editing of Pattern Program" in "Chapter 3" for details.
Or, enter each parameter, using the network terminal (option) and send it
to the main machine.
Note
Pattern Program Data Sheets
The pattern program filling in sheet described in "Chapter 7" can be used
for your convenience.
2.1 Composition of Pattern Program
0601-002
1-4
AKFEDT-ID
2.2 Composition of Operation Data
This data is used to generally manage the pattern program data.
This data is composed of the PCB data, the PEC recognition data, the PEC
recognition mark data, and the setup data.
Reference
Refer to "1.2 Operation Data" in "Chapter 3" for the details of each item.
A01 PCB Data Table 3A1
Ref. No. Data Name
A01_01 Comment 1 and Comment 2
A01_02 PCB size
X (Horizontal), Y (Vertical), T (Thickness) [mm]
A01_03 PCB origin offset
X (Horizontal), Y (Vertical) [mm], Z (Angle) [deg],
XY-Angle [deg],
X-Direction, Y-Direction, Z Angular Orientation
A01_04 PCB height offset [mm]
A01_05 Placement Reference
A01_06 PCB locate Sequence
A01_07 PCB transfer Sequence
A01_08 Pre-Placed component thickness
Top, Bottom [mm]
A01_09 PCB transfer speed
Input, Between Stages, Output
A01_10 PCB transfer speed des
Avoid comp deviation
(Input, Between Stages, Output)
Speed 1 [mm/sec], Speed 2 [mm/sec],
Acceleration [G]
Stop position control
(Input, Positioning 1, Center, Positioning 2, Output)
Timer [msec], Position [mm]
A01_11 Input Conveyor
Y Position arrange speed setup
(% deceleration) [%]
A01_12 Output Conveyor
Y Position arrange speed setup
(% deceleration) [%]
2.2 Composition of Operation Data
0601-002
1-5
AKFEDT-ID
Ref. No. Data Name
A01_13 PCB locate mode
Stage 1 and Stage 2
Operation
The 1st sp dclr setting([%] deceleration) [%],
The 2nd sp dclr setting([%] deceleration) [%],
Z Clamp
Delay Timer 1 [msec],
Delay Timer 2 [msec],
Operation waiting time [msec]
A01_14 Placement mode
Stage 1 and Stage 2
A01_15 Recovery regulation
U-N (Stage 1/Stage 2)
Block Sort (Stage 1/Stage 2)
2.2 Composition of Operation Data
0601-002
