Rotating the Machine Head
Before any work on the machine itself, pull the mains
plug.
The machine head can be
rotated with respect to
the machine housing in
90° steps. In this man-
ner, the On/Off switch
can be brought into a
more convenient posi-
tion for special working
situations, e. g., for cut-
ting operations using the
cutting guide with dust
extraction protection
guard 20 or for left-hand-
ed persons.
Completely unscrew the four screws. Rotate the machine
head carefully, without removing it from the housing, to the
new position. Screw in and tighten the four screws again.
Dust/Chip Extraction
Dust from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dust can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dust, such as oak or beech dust, is considered car-
cinogenic, especially in connection with wood-treatment
additives (chromate, wood preservative). Materials con-
taining asbestos may only be worked by specialists.
– As far as possible, use a dust extraction system suitable
for the material.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.
Prevent dust accumulation at the workplace. Dust can
easily ignite.
Operation
Starting Operation
Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.
Hold power tool by insulated gripping surfaces 22 and
auxiliary handle 5 only. The accessory may contact hid-
den wiring or its own cord. Accessory contacting a “live”
wire may make exposed metal parts of the power tool “live”
and shock the operator.
When operating the machine with power from mobile genera-
tors that do not have sufficient reserve capacity or are not
equipped with suitable voltage control with starting current
amplification, loss of performance or untypical behavior can
occur upon switching on.
Please observe the suitability of the power generator being
used, particularly with regard to the mains voltage and fre-
quency.
Switching On and Off
To start the machine, first slide the lock-off button 3 to the
rear and then push the On/Off switch 2 and keep it pressed.
To switch off the machine, release the On/Off switch 2.
Check grinding tools before using. The grinding tool
must be mounted properly and be able to move freely.
Carry out a test run for at least one minute with no load.
Do not use damaged, out-of-centre or vibrating grind-
ing tools. Damaged grinding tools can burst and cause in-
juries.
Working Advice
Before any work on the machine itself, pull the mains
plug.
Exercise caution when cutting slots in structural walls;
see Section “Information on Structures”.
Clamp the workpiece if it does not remain stationary
due to its own weight.
Do not strain the machine so heavily that it comes to a
standstill.
After heavily straining the power tool, continue to run
it at no-load for several minutes to cool down the acces-
sory.
Do not touch grinding and cutting discs before they
have cooled down. The discs can become very hot while
working.
Do not use the power tool with a cut-off stand.
Rough Grinding
Never use a cutting disc for roughing.
The best roughing results are achieved when setting the ma-
chine at an angle of 30° to 40°. Move the machine back and
forth with moderate pressure. In this manner, the workpiece
will not become too hot, does not discolour and no grooves
are formed.
max.
[mm]
[mm]
D b d [min
-1
] [m/s]
100
115
6
6
16
22
11000
11000
80
80
100
115
–
–
–
–
11000
11000
80
80
70
70
30
30
M10
M14
11000
11000
45
45
b
d
D
D
D
b
d
OBJ_BUCH-1556-005.book Page 11 Wednesday, July 20, 2016 11:23 AM
12 | English
1 609 92A 1WG | (20.7.16) Bosch Power Tools
Flap Disc
With the flap disc (accessory), curved surfaces and profiles
can be worked.
Flap discs have a considerably higher service life, lower noise
levels and lower sanding temperatures than conventional
sanding sheets.
Cutting Metal
For cutting with bonded abrasives, always use the pro-
tection guard for cutting 13.
When cutting, work with moderate feed, adapted to the mate-
rial being cut. Do not exert pressure onto the cutting disc, tilt
or oscillate the machine.
Do not reduce the speed of running down cutting discs by ap-
plying sideward pressure.
The machine must al-
ways work in an up-
grinding motion. Other-
wise, the danger exists
of it being pushed un-
controlled out of the
cut.
When cutting profiles and square bar, it is best to start at the
smallest cross section.
Cutting Stone
Provide for sufficient dust extraction when cutting
stone.
Wear a dust respirator.
The machine may be used only for dry cutting/grinding.
For cutting stone, it is best to use a diamond cutting disc.
When using the cutting guide with dust extraction protection
guard 20, the vacuum cleaner must be approved for vacuum-
ing masonry dust. Suitable vacuum cleaners are available
from Bosch.
Switch on the machine
and place the front part
of the cutting guide on
the workpiece. Slide the
machine with moderate
feed, adapted to the ma-
terial to be worked.
For cutting especially
hard material, e. g., con-
crete with high pebble
content, the diamond
cutting disc can over-
heat and become dam-
aged as a result. This is
clearly indicated by circular sparking, rotating with the dia-
mond cutting disc.
In this case, interrupt the cutting process and allow the dia-
mond cutting disc to cool by running the machine for a short
time at maximum speed with no load.
Noticeably decreasing work progress and circular sparking
are indications of a diamond cutting disc that has become
dull. Briefly cutting into abrasive material (e.g. lime-sand
brick) can resharpen the disc again.
Information on Structures
Slots in structural walls are subject to the Standard DIN 1053
Part 1, or country-specific regulations.
These regulations are to be observed under all circumstanc-
es. Before beginning work, consult the responsible structural
engineer, architect or the construction supervisor.
Maintenance and Service
Maintenance and Cleaning
Before any work on the machine itself, pull the mains
plug.
For safe and proper working, always keep the machine
and ventilation slots clean.
In extreme conditions, always use dust extraction as
far as possible. Blow out ventilation slots frequently
and install a portable residual current device (PRCD).
When working metals, conductive dust can settle in the in-
terior of the power tool. The total insulation of the power
tool can be impaired.
Please store and handle the accessory(-ies) carefully.
If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.
After-sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions
concerning our products and their accessories.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the nameplate of
the product.
