Parameter Definition
Board Thickness This parameter is used by the machine to set correct vision and print heights.
Minimum 0.20mm
Maximum 6.00mm
Increments 0.1mm
Underside Clearance This parameter determines the clearance provided between the underside of
the board and the top of the machine tooling to allow for components on the
underside of the board.
Minimum 3mm
Maximum 42mm
Increment 0.1mm
Default 19mm
Tooling Type This determines which type of board support is to be used with this particular
product. Options are:
Autoflex, Vacuum, Magnetic Pillars, Vac for Flex
See Tooling
Flatten Vacuum Delay This parameter determines the duration of vacuum applied whilst the board is
pressed against the underside of the screen with Vac for Flex enabled.
Minimum 0 sec
Maximum 5 secs
Default 2 secs
Increment 0.1 sec
Separation Vacuum
Delay
This parameter determines the duration of the vacuum applied after printing
and before the rising table is lowered to separation height with Vac for Flex
enabled.
Minimum 0 sec
Maximum 5 secs
Default 2 secs
Increment 0.1 sec
Print Front Limit This determines the distance from the front edge of the board that printing
must start.
Minimum -6.5mm
Maximum Board width set into the board file
Increment 0.1mm
Default 0mm
NOTE
With Paste Trails enabled or ProFlow fitted the minimum value is 0mm
Print Rear Limit This determines the distance from the rear edge of the board that printing
must start.
Minimum -6.5mm
Maximum Board width set into the board file
Increment 0.1mm
Default 0mm
NOTE
With Paste Trails enabled or ProFlow fitted the minimum value is 0mm
Board Stop X This parameter determines the distance from the centre line of the machine to
the board stop position.
Minimum 50mm
Maximum 310mm
Increment 0.1mm
Default Half of the board length set in the board
file, (Board located centrally)
NOTE
Not used while remote board stop is fitted.
Software Version 6 User Manual 1.93
MACHINE PROGRAMMING
MENU PARAMETERS
Parameter Definition
Board Stop Y This parameter determines the distance from the fixed rail to the board stop
position.
Minimum 25mm
Maximum Board width minus 20mm
Increment 0.1mm
Default Two thirds of the board width
NOTE
Not used while remote board stop is fitted.
Remote Board
Stop X
This parameter determines the displacement of the remote board stop from
the camera reference position.
Minimum Minimum Board Length ö 2
Maximum Board Length
Increment 0.1
Default Board Length ö 2
NOTE
Only used while remote board stop is fitted.
Right Feed Delay This parameter sets a time delay on the board stop to allow for irregular
shaped boards when fed from the right.
Minimum 0sec
Maximum 3secs
Increments 0.1sec steps
NOTE
Not used while remote board stop is fitted.
Alignment Weighting This is only used in 2 fiducial mode. This parameter sets a value determining
how much of the fiducial spacing error is assigned to fiducial 2.
Minimum 0%
Maximum 100%
Increment 1%
Default 50%
See vision system
X Align Weighting This is only used in 3 fiducial mode. This parameter sets a value determining
where the X axis alignment should be optimized.
Minimum 0%
Maximum 100%
Increment 1%
Default 50%
See vision system
Y Align Weighting This is only used in 3 fiducial mode. This parameter sets a value determining
where the Y axis alignment should be optimized.
Minimum 0%
Maximum 100%
Increment 1%
Default 50%
See vision system
Alignment Mode This parameter determines the mode used for board to screen alignment. The
Non Vision option is only available from the configuration file. Options
available are:
2 fiducial; 3 fiducial.
Default 2 fiducial
Fiducial 1 X coordinate Distance of first fiducial from the right or left hand edge of the board
(configuration dependent).
Minimum 1mm
Maximum Board Length
Increment 0.1mm
Default 1mm
1.94 User Manual Software Version 6
MACHINE PROGRAMMING
MENU PARAMETERS
Parameter Definition
Fiducial 1 Y coordinate Distance of the first fiducial from the front edge of the board.
Minimum 1mm
Maximum Board Width
Increment 0.1mm
Default 1mm
Fiducial 2 X coordinate Distance of second fiducial from the right or left hand edge of the board
(configuration dependent).
Minimum 1mm
Maximum Board Length
Increment 0.1mm
Default 1mm
Fiducial 2 Y coordinate Distance of the second fiducial from the front edge of the board.
Minimum 1mm
Maximum Board Width
Increment 0.1mm
Default 1mm
Fiducial 3 X coordinate Distance of third fiducial from the right or left hand edge of the board
(configuration dependent).
Minimum 1mm
Maximum Board Length
Increment 0.1mm
Default 1mm
Fiducial 3 Y coordinate Distance of the third fiducial from the front edge of the board.
Minimum 1mm
Maximum Board Width
Increment 0.1mm
Default 1mm
Select Mark X Distance of the select mark from the right or left hand edge of the board
(configuration dependent).
Minimum 0mm
Maximum Board Length
Increment 0.1mm
Default 148.5mm
NOTE
Only used while Selective Print/Pass is enabled in Set Preferences.
Select Mark Y Distance of the select mark from the front edge of the board (configuration
dependent).
Minimum 0mm
Maximum Board Width
Increment 0.1mm
Default 13mm
NOTE
Only used while Selective Print/Pass is enabled in Set Preferences.
Board 1 Fiducial Type This determines the type of model to be used for this fiducial. Options are
Circle; Rectangle; Diamond; Triangle; Double Square; Cross; Video model.
See vision system
Board 2 Fiducial Type This determines the type of model to be used for this fiducial. Options are
Circle; Rectangle; Diamond; Triangle; Double Square; Cross; Video model.
See vision system
Board 3 Fiducial Type This determines the type of model to be used for this fiducial. Options are
Circle; Rectangle; Diamond; Triangle; Double Square; Cross; Video model.
See vision system
Select Mark Type This determines the type of model to be used on the board for the select mark.
Options are Circle; Rectangle; Diamond; Triangle; Double Square; Cross;
Video model.
See vision system
NOTE
Only used while Selective Print/Pass is enabled in Set Preferences.
Software Version 6 User Manual 1.95
MACHINE PROGRAMMING
MENU PARAMETERS
