Parameter Definition Dry Clean Speed This parameter sets the speed of the screen clean dry wipe for optimization of the blue or silver USC and the speed of the screen clean return stroke for the Vortex USC. Minimum 10 mm…
Parameter Definition
ProFlow Idle Pressure This is the pressure applied to paste in the ProFlow unit between kneading
and printing, and between print strokes.
Maximum 4 bar
Minimum 0 bar
Increments 0.2 bar
Default 0.4 bar
NOTE
This parameter is only available if the software controlled regulator is fitted.
Flood Speed This parameter sets the flood blade speed across the screen when performing
a flood stroke.
Minimum 10mm/sec
Maximum 150mm/sec
Increments 1mm/sec
Flood Height This parameter sets the height of the flood blade above the screen during a
flood stroke.
Minimum 0mm
Maximum 5mm
Increments 0.02mm
Dwell Height The parameter allows the user to set the squeegee dwell height. Setting of a
lower height helps the media to stay evenly spread across the length of the
squeegee when a less viscous media is used. Setting a high height allows
viewing of the paste roll.
Minimum 5mm
Maximum 40mm
Increment 1mm
Default 30mm
Dwell Speed This preference adjusts the speed at which the squeegee moves to dwell
height. A slower speed helps to reduce the spreading of a less viscous media,
ie flux. It should be noted that decreasing this speed causes the cycle time to
increase.
Minimum 10mm/sec
Maximum 30mm/sec
Increment 1mm/sec
Default 24mm/sec
Screen Clean Mode 1
(Including Vacuum)
This parameter sets the mode of operation of the screen cleaner for the first
clean mode. When selected this parameter opens a window that allows a
screen clean option sequence to be chosen. The sequence includes six stages,
each of which may be one of the following cleaning operations:
WET, DRY, VAC, NONE
A warning is given if the end stroke is wet.
Screen Clean Rate 1 This parameter sets the number of print cycles between the cycling of the
screen cleaner for the first screen clean rate.
Minimum 0 (Screen cleaner off)
Maximum 200
Increment 1
Screen Clean Mode 2
(Including Vacuum)
This parameter sets the mode of operation of the screen cleaner for the second
clean mode. When selected this parameter opens a window that allows a
screen clean option sequence to be chosen. The sequence includes six stages,
each of which may be one of the following cleaning operations:
WET, DRY, VAC, NONE
A warning is given if the end stroke is wet.
Clean Screen Rate 2 This parameter sets the number of print cycles between the cycling of the
screen cleaner for the second screen clean rate.
Minimum 0 (Screen cleaner off)
Maximum 200
Increment 1
Print Vacuum mode This parameter determines the state of the vacuum during the print and flood
stages of the cycle. The parameter is only available if Adhesive has been
selected in the Print Mode parameter.
ON, OFF
Software Version 6 User Manual 1.99
MACHINE PROGRAMMING
MENU PARAMETERS
Parameter Definition
Dry Clean Speed This parameter sets the speed of the screen clean dry wipe for optimization of
the blue or silver USC and the speed of the screen clean return stroke for the
Vortex USC.
Minimum 10 mm/sec
Maximum 120mm/sec
Default 30mm/sec
Increments 1mm/sec steps
Wet Clean Speed This parameter sets the speed of the screen clean wet wipe for optimization.
Minimum 10 mm/sec
Maximum 100mm/sec
Increments 1mm/sec steps
Vac Clean Speed This parameter sets the speed of the screen clean Vacuum for optimization.
Minimum 10 mm/sec
Maximum 100mm/sec
Increments 1mm/sec steps
Clean After Downtime This function provides the facility for the screen to be cleaned automatically
with a pre-programmed clean after a pre-programmed idle time. Clean After
Downtime only becomes active after the machine has performed at least one
print after it is powered up. When selected this parameter opens a window
that allows a clean after knead option sequence to be chosen. The sequence
includes six stages, each of which may be one of the following cleaning
operations:
WET, DRY, VAC, NONE
Clean After The Automatic screen clean after downtime process chosen in the above
menu parameter is carried out after a countdown of the number of minutes set
in this parameter.
Minimum 5 mins.
Maximum 120 mins.
Increment 1 min.
Clean After Knead This function is active if the machine is running in automatic mode. If this
option is enabled and a paste dispense has been performed (either MANUAL
or AUTOMATIC) a paste knead is performed as defined by the paste knead
parameters in the board file on the next board immediately following the
paste dispense. When selected this parameter opens a window that allows a
clean after knead option sequence to be chosen. The sequence includes six
stages, each of which may be one of the following cleaning operations:
WET, DRY, VAC, NONE
Front Start Offset
(Blue/Silver USC)
This parameter determines the distance from the front edge of the board that
the cleaning stroke must start.
Minimum 0mm
Maximum 60mm
Increments 1mm
Front Start Offset
(Vortex USC)
The distance, in from the front edge of the board, at which the cleaner is to
finish.
Minimum -60mm
Maximum 60mm
Default 30mm
Increment 1mm
Rear Start Offset
(Blue/Silver USC)
This parameter determines the distance from the rear edge of the board that
cleaning must complete.
Minimum 0mm
Maximum 60mm
Increments 1mm
Rear Start Offset
(Vortex USC)
The distance, in from the rear edge of the board, at which the cleaner is to
start.
Minimum -60mm
Maximum 60mm
Default 30mm
Increment 1mm
1.100 User Manual Software Version 6
MACHINE PROGRAMMING
MENU PARAMETERS
Parameter Definition
Vortex Cassette Life
(Vortex USC)
This parameter sets the number of cleaning strokes that are applied before a
cleaning cassette is replaced.
Minimum 0
Maximum 200
Default 20
Increment 1
Vortex Clean Rate
(Vortex USC)
This parameter sets the frequency (in print cycles) at which screen cleaning
occurs.
Minimum 0
Maximum 200
Default 0
Increment 1
Vortex Solvent Rate
(Vortex USC)
This parameter sets the frequency (in cleaning cycles) at which solvent is
dispensed.
Minimum 1
Maximum 10
Default 1
Increment 1
Vortex Vacuum Start
(Vortex USC)
The distance, in from the front edge of the board, where vacuum is applied.
Minimum Vacuum Stop
Maximum Board Width
Default 0mm
Increment 1mm
Vortex Vacuum Stop
(Vortex USC)
The distance, in from the front edge of the board, where vacuum application
is stopped.
Minimum -100mm
Maximum Vacuum Stop
Default 0mm
Increment 1mm
Vortex Vacuum Rate
(Vortex USC)
This parameter sets the frequency (in cleaning cycles) at which vacuum is
applied.
Minimum 1
Maximum 10
Default 1
Increment 1
Vortex Vacuum Period
(Vortex USC)
This parameter sets the period for which vacuum is applied.
Minimum 1 sec
Maximum 10 secs
Default 5 secs
Increment 1 sec
Paste Dispense Rate This parameter sets the number of print cycles which occur between cycling
of the paste dispense system.
Minimum 0 (Dispenser switched off)
Maximum 100
Increment 1
Paste Dispense Speed This parameter sets the speed at which the paste dispenser moves across the
screen thereby determining the amount of paste deposited on the screen.
Minimum 10mm/sec
Maximum 100mm/sec
Increment 1mm/sec
Software Version 6 User Manual 1.101
