Comms Enabled Comms Disabled Equipment Constant Change Acknowledge Terminal Message Comms Knead Paste Request Comms Condition Paste Request Control State Change To Local Control State change To Offline Control State Chan…
Board Clamp Stuck Board Stuck In Rails Unable To Find Fiducial
Rail Lifted Error Pressure Error File Error
Unable To Recover Recovery Started Recovered
Upline Transfer Error Downline Transfer Error Dual Shuttle Fault
Screen Elevator Comms Fault Screen Elevator Fault Screen Changer Fault
Lid Bolt Fault Alignment Out Of Range Line Power On
Line Power Off Cover Open Cover Closed
Printer Ready Head Raised Head Closed
Paste Dispensing Paste Cartridge Empty Cycle Aborted
Cycle Completed Cleaning Screen Parameter Adjusted
Setup Started Product Loaded New Product
Product Data Changed Screen Unloaded Screen Loaded
Tool Change Started Tool Change Complete Setup Ended
Start Print Cycle Board Received End Print Cycle
Printed Board Ready Board Printed Operator Log On
Operator Log Off Clear Batch Count Start Maintenance
End Maintenance Pressure Recalibrated Offset Recalibrated
XY Scale Recalibrated Theta Recalibrated Configuration Changed
Start Diagnostics End Diagnostics Flood Height Reset
Camera Ref Reset Thickness Recalibrated Vision Height Reset
Print Height Reset Autoflex Status Reset Software Updated
New Event Log Front Reference Position Reset Front Reference Height Reset
Rear Reference Height Reset Check Cleaner Paper Cleaner Solvent Low
Barcode Read Failure Barcode Mismatch Screen Couplings Not Extended
Mint Reply Timeout Camera X Failed To Position Camera Y Failed To Position
Aperture Blockage Stencil Smear Paste Present
Bridging alarm Alignment Alarm Head Left Partly Open
Head Moved To Safe State Inspection Cycle Complete Clock Change Request
Clock Changed Board Delivered and Removed Event Log Disc File Full
ProFlow Error Autoflex Tooling Selected Autoflex Tooling Deselected
AutoFlex Tooling Enabled AutoFlex Tooling Disabled Tooling Data Has Been Changed
CAN Node Comms Lost. Node CAN Node Comms Active. Node CAN Bus Comms Lost. Bus
CAN Bus Comms Active. Bus Invalid CAN Response Product Directory Request
Current Product Request Erase Product Request Rename Product Request
Load Product Request Download Product Request Upload Product Request
Download Configuration Request Upload Configuration Request Upload Management Data Request
Clear Batch Data Request Clear Session Data Request Upload Event Log Request
Clear Event Log Request Comms Start Request Comms Stop Request
Update Mode Request Comms Error Parameter Info Uploaded
Formatted Parameters Uploaded Formatted Parameters Downloaded Comms Status Request
Comms Rebuild Product List Comms Adjust Paste Rate Comms Adjust Front Pressure
Comms Adjust Rear Pressure Comms Adjust Print Gap Comms Adjust Seperation Speed
Comms Adjust Clean Screen Comms Adjust FWD_X Offset Comms Adjust FWD_Y Offset
Comms Adjust FWD_T Offset Comms Adjust REV_X Offset Comms Adjust REV_Y Offset
Comms Adjust REV_T Offset Comms Dispense Paste Request Comms Clean Screen Request
2.8 User Manual Software Version 6
SET PREFERENCES
PREFERENCES
Comms Enabled Comms Disabled Equipment Constant Change
Acknowledge Terminal Message Comms Knead Paste Request Comms Condition Paste Request
Control State Change To Local Control State change To Offline Control State Change To Remote
GEM Spooling Activated Gem Spooling Deactivated GEM Spool Transmission Failure
Operator Command Issued Remote Barcode Received Comms Adjust ProFlow Pressure
Options.enb file Attribute Error Volume Alarm Evaluation Dongle Detected
Valid Dongle Detected Dongle Error Dongle Changed
Print Speed Front Print Speed Rear Print Speed
Comms Adjust Print Speed Comms Adjust Front Print Speed Comms Adjust Rear Print Speed
Vortex Cassette Replaced Maintenance Monitoring Initialis The Monthly Service is Due
The Six Monthly Service is Due The Yearly Service is Due Equipment Recovery
Equipment Setup Equipment Ready Equipment Maintenance
Equipment Waiting Equipment Running Equipment Down
Tooling Hardware Sets which type of tooling is fitted, options are:
Autoflex; Vacuum; Magnetic; Vac For Flex
The default is Magnetic.
Autoflex Entry Sets whether the Fine Pitch Autoflex pin co-ordinates are referenced by the
distance of the pin, in X and Y, from the front left of the Autoflex table
(absolute), or from the column letters and row numbers (grid), options are:
Absolute; Grid
Fiducial Reference Sets whether the fiducial co-ordinates are specified relative to the front/left or
front/right corner of the board:
Left; Right
The default is Left.
Product Barcode
H/W
Sets whether or not the product barcode reader is fitted (265GSX only), options
are:
Fitted; Not Fitted
Screen Barcode
H/W
Sets whether or not the screen barcode reader is fitted (265GSX only), options
are:
Fitted; Not Fitted
Software Version 6 User Manual 2.9
SET PREFERENCES
PREFERENCES
Remote Barcode
Hardware
This preference is only available if the TCP/IP version of Host Comms is used
and Serial Host Comms is not selected from the Comms Protocol set preference,
options are:
Enabled; Disabled
The optional External Product Barcode Reader provides a generic bar code
interface for the capturing by GEM and SPC of a product bar code before the
product is passed to the printer. Use of the reader enables a host program to
decide on the action to be taken for this product and provides a method for SPC
to log product details for tracking.
The DEK printer acts as a dumb receiver of barcode data and provides no set up,
configuration or triggering information for the barcode reader.
Compatible Bar
Code Reader
The printer has been designed to operate with SICK Model CLV 212 Bar code
reader.
Options The two options available for the External Barcode parameter are Enabled and
Disabled.
If the bar code reader is set to Disabled, COM 1 is setup as per previous versions
of software and enabled to accept serial host comms.
If the bar code readeris set to Enabled, COM 1 isset to use the external bar code
reader and the option Serial Comms is removed from the Comms Protocol
parameter in the Set Preferences menu.
ProFlow Contact
Position
This parameter sets the height of theProFlow printhead so that it just touches the
stencil surface.
Min - 10mm
Max + 10mm
Increments 0.1mm
The default is 0mm.
ProFlow Down Stop
Position
This parameter pre-tensions the squeegee suspension springs to provide
ProFlow with a zero pressure datum.
Min - 10mm
Max 10mm
Increments 0.1mm
The default is 0mm.
