The screen library menu parameters are defined in the table below: Parameter Definition Screen Record ID The identity of the screen type library record containing a text string that matches the Screen Type selected. Form…

Change Mode

Option

Sets the screen change mode, options are:

Manual; Dual Shuttle

NOTE

The dual shuttle option is only relevant on a machine with a dual shuttle unit

fitted.

Screen Size Sets the screen size frame:

265; FUJI; 249; SANYO; SCREEN LIBRARY

With Screen Library enabled the printer is provided with detailed screen

dimensional information from a ‘read only’ library. This information is stored

within the machine configuration and product files.

Once selected in Set Preferences, detailed frame dimensions are provided to the

printer. In Edit Current Process Parameters, the parameter Image Data provides

comprehensive location and mesh details to the printer.

To enable screen library files carry out the following:

Highlight Screen Size in the Set Prefs page.

Using Incr. or Decr. select Screen Library.

Edit Data is now available on the menu bar.

Select Edit Data, the following window and menu bar is displayed:

Use Incr.orDecr. to select the required Screen Type. If no valid screen library

files are found, the default file DEK 265 Central Image is displayed.

Use Next or Previous to select and Incr. or Decr. to modify the screen frame

parameters as required.

Software Version 6 User Manual 2.11

SET PREFERENCES

PREFERENCES

SCREEN TYPE

SCREEN LENGTH

SCREEN WIDTH

FRAME FRONT

FRAME REAR

FRAME LEFT

FRAME RIGHT

DEK 265 CENTRAL IMAGE

XXX

Screen Frame Configuration

The screen library menu parameters are defined in the table below:

Parameter Definition

Screen Record ID The identity of the screen type library record containing a text string that

matches the Screen Type selected.

Format Maximum 32 character text string

Default DEK 265 Central Image

Screen Length This parameter sets overall dimension front to rear of the screen frame or

adaptor.

Minimum 550mm

Maximum 860mm

Increment 0.1mm

Default 736.6mm

Screen Width This parameter sets the overall dimension left to right of the screen frame or

adaptor.

Minimum 580mm

Maximum 736.6mm

Increment 0.1mm

Default 736.6mm

Frame Front This parameter sets the distance between the outer edge of the screen frame

or adaptor and the inner edge of the frame, at the front of the frame.

Minimum 20mm

Maximum Screen Length - 250mm

Increment 0.1

Default 38.1mm

Frame Rear This parameter sets the distance between the outer edge of the screen frame

or adaptor and the inner edge of the frame, at the rear of the frame.

Minimum 20mm

Maximum Screen Length - 250mm

Increment 0.1mm

Default 38.1mm

Frame Left This parameter sets the distance between the outer edge of the screen frame

or adaptor and the inner edge of the frame, at the left of the frame.

Minimum 20mm

Maximum Screen Length - 250mm

Increment 0.1mm

Default 38.1mm

Frame Right This parameter sets the distance between the outer edge of the screen frame

or adaptor and the inner edge of the frame, at the right of the frame.

Minimum 20mm

Maximum Screen Length - 250mm

Increment 0.1mm

Default 38.1mm

Feature Licensing Sets whether the Feature Licensing facility is fitted to the machine.

Enabled; Disabled

Introduction The Feature Licensing facility enables a user to request and install a licence to

run a new feature on the machine. The Features Licensed window lists all the

licences available and applicable to the machine and current software.

Licence Request 1.

Select Maint. (F8).

Maint.

2.12 User Manual Software Version 6

SET PREFERENCES

PREFERENCES

Select Set Prefs (F5).

Set

Prefs

The following window is displayed:

Using Next and Previous (F4 -F5) highlight Feature Licensing.

Next Previous

Select Edit Features (F1).

Edit

Features

The following window and menu bar is displayed:

Software Version 6 User Manual 2.13

SET PREFERENCES

PREFERENCES

Set Preferences

..more

TRANSPORT MODE

MACHINE UNITS

UPLINE PROTOCOL

DOWNLINE PROTOCOL

TRANSFER PERIOD

PASTE DISPENSE POS

EVENT RECORDING

TOOLING HARDWARE

FIDUCIAL REFERENCE

REMOTE BARCODE H/W

CHANGE MODE OPTION

SCREEN SIZE

PAPER/SOLV/PASTE LOW

FEATURE LICENSING

LEFT TO RIGHT

METRIC

NO FMI

60 secs

FRONT

CUSTOM

MAGNETIC

LEFT

NOT FITTED

MANUAL

265

WAR N

ENABLED

Basic Screen Insp.

Basic Board Insp.

Advanced Screen Insp.

Advanced Board Insp.

SEC GEM Option

Net Files Option

Flexi Print

Selective Prnt Pass

Tooling Monitoring

Features L

cense

y 112737

DISABLED
