IP ADDRESS CONFIGURATION
For a 265GSX Machine to function in a network enviroment, correct setting of
its IP Address is necessary. The IP Address (Internet Protocol Address)
provides a unique global address for both the machine and the network.
Note
IP Addresses must be provided by the sites Line or Network Manager.
TCP/IP Driver
(GEM and
NET_FILES)
The IP address of the printer must be set up in the TCP/IP driver. This can be
done when the PC/TCP software is installed using INSTALL.EXE. The set-up
can be re-configured later by running CONFIG.EXE in the PC/TCP directory.
The PC/TCP manual supplied with the PC/TCP software covers this in detail.
SDR Driver
(GEM only)
The IP addressof the printer must beset up in the SDR driver. To dothis edit the
SDR configuration file “c:\printer\conf170.cfg” (see next page) using a text
editor. The DOS program EDIT is suitable and can be used by typing the
following from the DOS prompt:
EDIT C:\printer\conf170.cfg
Set the PASSIVE ENTITY IPADDRESS to the printers “IP address”.
If there is more than one printer communicating with the GEM Host, set the
DEVICEID differently for each printer. The default value is 0x109 (265).
Alternative DEVICEID values should be chosen within the range
0x0000 - 0x7FFF (0 - 32767).
3.4 User Manual Software Version 6
HOST COMMUNICATIONS
IP ADDRESS CONFIGURATION
Configuration File /* SDR-DOS-170 Sample Configuration File*/
PORT 0:
PROTOCOL HSMS94
EQUIPMENT
PASSIVE ENTITY
PASSIVE ENTITY IPADDRESS 192.100.20.51
PASSIVE ENTITY TCPPORT 5265
T3 30
T5 5
T6 10
T7 5
T8 6
CONNECTION ESTABLISHMENT 5
CIRCUIT ASSURANCE 20
TGRACE 15
MEMORY STALL 5
WRITE STALL 7
START
DEVICE 0:
DEVICEID 0x109
PORT 0
START
Definitions of Fields The majority of these fields never need to be changed. They are described here
to give an understanding of how to configure the driver when changing IP
addresses, Device ID’s or some of the timer values.
Port 0: Defines this port as SECS port 0.
Protocol HSMS94 Selects the protocol that the SDR driver uses.
Equipment Defines that the printer end of the link is the equipment end.
Passive Entity Defines that the printer is the passive entity and that the host is expected to
establishthe TCP/IP connection. AGEM host is almost always the activeentity.
Passive Entity IP
Address
Sets the IP address of the printer.
Passive Entity TCP
Port 5265
Specifies a TCP Port number at which the passive entity waits for a connection
on this HSMS link. Typically a number beginning at 5000.
Software Version 6 User Manual 3.5
HOST COMMUNICATIONS
IP ADDRESS CONFIGURATION
T3 30 Sets the HSMS-SS T3 reply timeout to 30 seconds. If the printer does not
receive a reply within this time a S9F9 Transaction timeout error message is
transmitted.
T5 5 TheHSMS-SST5 Connect separation Timer value. Only used by an “ACTIVE”
entity.
T6 10 The HSMS-SS T6 Control Message Reply Timer value. should be less than T3
10 is a typical value.
T7 5 The HSMS-SS T7 Connect Timeout value. The time that the PASSIVE Entity
waits to receive a HSMS Select.req control message after a TCP/IP connection
has been established. If the time is exceeded the TCP/IP link is terminated.
T8 6 The HSMS-SS T8 Inter-character Timer value. The maximum time that SDR
driver waits for a TCP/IP recv operation to complete. If the time is exceeded the
TCP/IP link is terminated.
Connection
Establishment 5
Only used by an “ACTIVE” entity.
Circuit Assurance 20 Defines the frequency at which the SDR Driver initiates a HSMS Linktest
control transaction.
T Grace 15 A period during the start up of the link. when the SDR Driver accepts and
buffers messages from the printer software.
Memory Stall 5 This limits how long the SDR Driver tolerates a situation where all of its buffers
are full and the host is attempting to send more data. If the time is exceeded the
TCP/IP link is terminated.
Write Stall 7 This limits the amount of time that the SDR driver waits for TCP/IP to accept
data. If the time is exceeded the TCP/IP link is terminated.
Start This statement automatically enables the port when the printer starts up.
Device 0: This defines the printer as device 0.
Device ID 0x109 This allocates an ID to Device 0 (the printer). it is specified as a hexadecimal
number. The default is 0x109 (265 decimal).
