Error Message Intrepretation

Command Timed Out

(Screen Actuators)

This error reports that the actuator has failed to move to the

demanded position within the time period. Possible causes are:

Home sensor fault, if occurring during initialization.

Motor fault, if occurring during initialization.

Motor not running.

Mint card faulty.

Problem on the busy line from the mint card.

Command Timed Out

(Screen Change)

This error reports that the screen change has failed to move to the

demanded position within the time period. Possible causes are:

Home sensor fault, if occurring during initialization.

Motor fault, if occurring during initialization.

Motor not running.

Mint card faulty.

Problem on the busy line from the mint card.

Command Timed Out

(Front/Rear Squeegee)

This error reports that the front/rear squeegee has failed to move to

the demanded position within the time period. Possible causes are:

Home sensor fault, if occurring during initialization.

Motor fault, if occurring during initialization.

Motor not running.

Mint card faulty.

Problem on the busy line from the mint card.

Downline Board Transfer Fault This error reports that the time the downline interface has waited

for a board has exceeded the time-out.

Downline Machine Not available This error reports that the downline machine is unavailable to

accept the next board.

Dual Shuttle Fault This error reports that the 20 seconds time-out period has been

exceeded when loading or unloading a screen.

Event File Open Error This error reports that there was a problem opening the event log

backup file.

Failed to Determine Tooling

Deviation

This error reports that while monitoring the tooling deviation, the

number of samples (pressure variations) during the print stroke

was less than 2 or the minimum value was zero. This error

message is only valid where tooling deviation is authorized and

enabled.

Check tooling support is sufficient.

Check underside components are clear of tooling.

Front Squeegee Error This error reports that the front squeegee has failed to reach its

fully up position.

Front Squeegee Pressure Error When this error is detected a new window displays the set pressure

reading and the actual pressure reading.

File Error (To be added when details available)

Have All Tooling Pins Been

Removed ?

This message appears for the user to confirm that all magnetic

tooling pins have been removed, before setting up the machine for

a new board file that uses autoflex tooling.

Invalid Calibration Data.

Recalibrate ProFlow Heights

This error reports that the ProFlow calibration data is corrupt or

invalid.

Invalid Calibration Data.

Recalibrate Squeegee Heights

This error reports that the squeegee calibration data is corrupt or

invalid.

Lid Bolt Fault This indicates that the lid bolt has failed to either open or close.

Software Version 6 User Manual 4.5

ERROR MESSAGES

ERROR MESSAGE LISTING

Error Message Intrepretation

No Paste Knead Cycles Selected This error reports when Knead Paste is selected on main menu

page and Knead Deposits in Set Prefs is selected to 0 cycles.

Paste Carriage Error This error reports that the paste carriage has failed to reach its

home position.

Paste Cartridge Tilt Error This error reports that the paste cartridge mechanism has failed to

either make its up or down limit switches.

Pneumatic Power Down This error message reports that the pneumatic supply is either too

low or has been disconnected

Position Error

(Camera)

This error reports that the cameras actual position is not within the

tolerance of 1% of the designated position.

Position Error

(Print Carriage)

This error reports the print carriage actual position is not within

tolerance of its designated position.

Position Error

(Rising Table)

This error reports that the rising table has failed to reach its home

position.

Position Error

(Screen Load)

This error reports that a problem has occurred while unloading the

screen. Possible causes are:

Motor fault Sensor fault

Print Carriage Error This error reports that the print carriage has failed to move.

Proflow Downstop At Limit This error reports when the downstop reaches set limits whilst

using the jog buttons in Diagnostics (Drive Downstop Using Jog

Buttons).

Proflow at movement limit This error reports when the proflow reaches set limits whilst using

jog buttons in Diagnostics(Drive System Using Jog Buttons).

Rail Lifted Error, Check Tooling This error reports that either the left rail lifted sensor or the right

rail lifted sensor are out of their home positions when any of the

following moves are taking place:

Alignment of the screen

Board stop moving into position

Initialization of the machine

Initialization of the autoflex tooling

Possible causes are:

A misfed board

Tooling/object on the rising table striking the underside of the rails

Rear Squeegee Error This error reports that the rear squeegee failed to reach its fully up

position.

Rear Squeegee Pressure Error When this error is detected a new window displays the set pressure

reading and the actual pressure reading.

Rising Table Error This error reports that the rising table has either failed to reach its

fully down position or that when attempting to reach the required

height during the machine cycle did not achieve the positional

accuracy.

Rising Table Out of Position This error reports that either; the camera axes are not at the home

position when the rising table is to be lifted, or the rising table is at

a height greater than vision height by 1mm.

Screen Changer Drive Error

(265GSX only)

This error indicates that no screen movement has been detected

when the screen changer is attempting to move the screen either at

initialization or at a screen change request.

4.6 User Manual Software Version 6

ERROR MESSAGES

ERROR MESSAGE LISTING

Error Message Intrepretation

Screen Cleaner Out Of Position This error reports that the screen cleaner is out of position.

Possible causes are:

Screen Cleaner not at the home position.

Home sensor - enter diagnostics, digital inputs and check the

sensor changes state.

If a screen cleaner is not fitted , check that the home sensor is not

connected.

Screen Couplings Not Extended This error reports that the screen couplings have failed to extend

within the 4 second time-out period.

Screen Fiducial Not Found This error reports that the vision system has been unable to locate

the screen fiducial.

Screen Not Correctly Located.

Reposition !

( Lt machines only)

This error reports that a screen has not been detected by the screen

at rear sensor.

Screen XF Error This error reports that the X forward screen actuator failed to

initialize to its central datum.

Screen XR Error This error reports that the X rear screen actuator failed to initialize

to its central datum.

Screen Y Error This error reports that the Y screen actuator failed to initialize to

its central datum.

Set Pressure %2.21f Actual

Pressure %2.21f

(Front/Rear Squeegee)

This error reports if the front/rear squeegee pressure differs from

the pressure set by more than ± 1.00Kg.

Stop After Idle Time Exceeded This error reports if the idle time is exceeded, the options to

continue or abort are displayed. Continue resets the idle timer or

abort allows for Manual or Auto unload.

System Power Down This error reports that the 24V motor power has been switched off

either by the Emergency Stop button being activated (including

upline and downline external machines) or that the removable

frame access cover has been removed

System Suspended While Covers

Open

This error reports that whilst the machine was switched on, one or

more of the cover interlock switches were out of position.

Table Movement Inhibited,

Camera Not Home.

This error reports that the camera is over the table and the mint is

sent an instruction to move the rising table.

This Diagnostic Cannot Run Until

Proflow Is At home

This error reports if proflow is not in the home position (Print

Carriage Diagnostics only).

This Diagnostic Cannot Run With

Proflow Fitted

This error reports if in Print Carriage Diagnostics, Move Print

Carriage to Paste Position is selected.

Unable to Find Fiducial This error reports that the vision system is unable to locate the

relevant screen or board fiducial.

Upline Board Transfer Error This indicates that there is a problem in loading a board from the

upline machine.

Upline Machine Not Available This error reports that the upline machine is unavailable to accept

the next board.

Window Error This error reports that the menu structure has failed to open

correctly.

Software Version 6 User Manual 4.7
