SCREEN CHANGE (265Lt) The 265Lt Screen Change diagnostic module contains the following: Toggle Coupling Right On/Off Toggle Screen Clamps On/Off Clamp Screen Unclamp Screen Rear Screen Sensor On/Off The menu bar changes …
Toggle Screen
Clamps
Selecting this option alternately energizes the Screen Clamps, displaying On
status and de-energise them , displaying Off status.
Load Screen Selecting this option performs a load screen cycle.
Unload Screen Selecting this option performs an un-load screen cycle.
Front Screen
Sensor
This continuously displays the current status of the front screen sensor.
Centre Screen
Sensor
This continuously displays the current status of the centre screen sensor.
Rear Screen Sensor This continuously displays the current status of the rear screen sensor.
Exit Screen Sensor This continuously displays the current status of the sensor at the rear of the
machine.
Safety Screen
Sensor
This continuously displays the current status of the sensor at the front of the
machine.
Drive Coupling
Extended
This monitors and continuously displays that both drive couplings are fully
extended.
Software Version 6 User Manual 5.33
DIAGNOSTICS
SCREEN CHANGE (265GSX)
SCREEN CHANGE (265Lt)
The 265Lt Screen Change diagnostic module contains the following:
Toggle Coupling Right On/Off
Toggle Screen Clamps On/Off
Clamp Screen
Unclamp Screen
Rear Screen Sensor On/Off
The menu bar changes to the following:
RunDiagnost activates the diagnostic function, as selected by thehighlightbar.
Next/Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Exit returns operation to the module diagnostics page.
Toggle Coupling
Right
Selecting this option alternately energizes the drive coupling right solenoid,
displaying On status and de-energise it, displaying Off status. Toggle Coupling
Right has no function when the graduated scale and screen location blocks are
fitted as the right drive coupling is removed.
Toggle Screen
Clamps
Selecting this option alternately energizes the Screen Clamps, displaying On
status and de-energise them, displaying Off status.
Clamp Screen Selecting this option operates the right hand clamp, delays for one second,
operates the top clamps, delays for one second and releases the right hand screen
clamp.
Unclamp Screen Selecting this option ensures the right hand clamp is released and retracts the top
clamps.
Rear Screen Sensor This continuously displays the current status of the rear screen sensor.
5.34 User Manual Software Version 6
DIAGNOSTICS
SCREEN CHANGE (265Lt)
SCREEN CLEANER
Selecting this diagnostics module opens the following window:
NOTE
Toggle Paper Feed and Cleaner Paper Low/Advance are not present when the
Vortex under screen cleaner is fitted.
The menu bar changes to the following:
RunDiagnost activates the diagnostic function, as selected by thehighlightbar.
Next/Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes to the following:
Incr.
Incr./Decr. keys change the value of the cycle count.
Exit returns operation to the screen cleaner diagnostics page.
Toggle Dry Wipe
Blade
Selecting this diagnostic function lifts and lowers the cleaner body assembly,
displayingOn when the cleaner bodyassembly is liftedto the horizontalposition
and Off when the cleaner body assembly is lowered.
Software Version 6 User Manual 5.35
DIAGNOSTICS
SCREEN CLEANER
Screen C
l
eaner D
i
agnost
i
cs
ON
ON
ON
Cleaner Paper Low/Advance
Cleaner Solvent Low
Pinch Valve Fitted
ON
ON
ON
ON
ON
ON
Toggle Dry Wipe Blade
Toggle Pinch Valve (if fitted)
Toggle Paper Feed
Toggle Vacuum
Toggle Solvent Feed/Tank Press
Toggle Screen Cleaner Home Clamp
Cycle Pinch Valve
Cycle Clean Blade
Cycle Count
Done :-
0, To go :-
50
Cleaner Cycle Parameters
CYCLE COUNT
50.0
Cycles
