AUTOFLEX TOOLING (STANDARD) Selecting this diagnostics module opens the following window: The menu bar changes displaying the following: Next / Previous keys move the highlight bar up and down the list of selectable diag…

Toggle Left GBO Selecting this diagnostic function sends a Good Board Out (GBO) signal to the

upline machine.

Toggle Right SRO Selecting this diagnostic function sends a Send Request Out (SRO) signal to the

ddownline machine.

Toggle Right RRO Selecting this diagnostic function sends a Receive Request Out (RRO) signal to

the downline machine.

Toggle Right ARO Selecting this diagnostic function sends an Acknowledge Request Out (ARO)

signal to the downline machine.

Toggle Right TRO Selecting this diagnostic function sends a Transfer Request Out (TRO) signal to

the downline machine.

Toggle Right MAO Selecting this diagnostic function sends a Machine Available Out (MAO) signal

to the downline machine.

Toggle Right GBO Selecting this diagnostic function sends a Good Board Out (GBO) signal to the

downline machine.

Left ARI This diagnostic function continuously displays whether the upline machine is

sending an Acknowledge Request In (ARI) signal.

Left TRI This diagnostic function continuously displays whether the upline machine is

sending a Transfer Request In (TRI) signal.

Left MAI This diagnostic function continuously displays whether the upline machine is

sending a Machine Available In (MAI) signal.

Left SRI This diagnostic function continuously displays whether the upline machine is

sending a Send Request In (SRI) signal.

Right ARI This diagnostic function continuously displays whether the downline machine is

sending an Acknowledge Request In (ARI) signal.

Right TRI This diagnostic function continuously displays whetherthe downline machine is

sending a Transfer Request In (TRI) signal.

Right MAI This diagnostic function continuously displays whether the downline machineis

sending a Machine Available In (MAI) signal.

Right SRI This diagnostic function continuously displays whether the downline machine is

sending a Send Request In (SRI) signal.

Software Version 6 User Manual 5.41

DIAGNOSTICS

FOREIGN MACHINE INTERFACE

AUTOFLEX TOOLING (STANDARD)

Selecting this diagnostics module opens the following window:

The menu bar changes displaying the following:

Next / Previous keys move the highlight bar up and down the list of selectable

diagnostic functions.

RunDiagnost activates the diagnostic function, as selected by thehighlightbar.

Exit returns operation to the module diagnostics page.

Tooling Pins Selecting this diagnostic function alternately lifts and lowers all the pins,

continuously displaying the current status.

Clamp Enable Selecting this diagnostic function alternately switches the electro-magnet

clampsonor off, continuously displaying the current status. Any pins that are up

when the clamp is switched off automatically lower.

Clamp Power Selecting this diagnostic function alternately switches the power through the

electro-magnetic coils between high and low, continuously displaying the

current status.

5.42 User Manual Software Version 6

DIAGNOSTICS

AUTOFLEX TOOLING (STANDARD)

Autof

ex D

agnost

Down

Tooling Pins

Clamp Enable

Clamp Power

Change Pin Status

Cycle Autoflex Tooling

Change Pin Status Selecting this diagnostic function enables different pin patterns to be exercised.

On selection the following window opens:

The menu bar changes to the following:

Left, Right, Up and Down keys move the cursor to enable individual pins to be

selected.

Lower or Raise keys enable the selected pin to be raised or lowered.

Set Status key enables the autoflex to set the selected pin pattern. The message

Setting Up Autoflex Tooling is displayed in the message window.

Exit returns operation to the autoflex diagnostics page.

Cycle Autoflex

Tooling

Selecting this diagnostic function cycles the autoflex pins in a set pattern. The

pattern is as follows:

1. All the pins are raised.

2. The pins are lowered leaving a third raised, every third pin.

3. All the pins are raised.

4. The pins are lowered leaving a second third raised.

5. All the pins are raised.

6. The pins are lowered leaving the last third raised.

The process repeats until the Stop key is pressed.

Software Version 6 User Manual 5.43
