Solvent Replenishment 1. Remove the solvent tank cap from the solvent tank. Software Version 6 User Manual 9.41 CONSUMABLE REPLENISHMENTS VORTEX UNDERSCREEN CLEANER W ARNING PROTECTIVE CLOTHING . APPROVED PROTECTIVE CLOT…
15. If the set preference is set to suspend, the following window is displayed:
The tricoloured beacon shows red.
16.
Select End Run (F8).
End
Run
17.
Press Head (F2).
Head
The message ‘Raise Head using 2-button Control’ is displayed.
18. Raise the printhead using two button control. Fit the printhead support.
9.40 User Manual Software Version 6
CONSUMABLE REPLENISHMENTS
VORTEX UNDERSCREEN CLEANER
Solvent Replenishment
1. Remove the solvent tank cap from the solvent tank.
Software Version 6 User Manual 9.41
CONSUMABLE REPLENISHMENTS
VORTEX UNDERSCREEN CLEANER
WARNING
PROTECTIVE CLOTHING. APPROVED PROTECTIVE CLOTHIN
G
SHOULD BE WORN BY SOLDER PASTEAND SOLVENT HANDLERS
AT ALL TIMES TO ELIMINATE FUME INHALATION, EYE
CONTACT,SKINCONTACTANDINGESTION.
WARNING
SOLVENTSOLUTION. DONOTMIXSOLVENTSOLUTIONS. FLUSH
THE SOLVENT TANK THOROUGHLY WHEN CHANGING TO
A
DIFFERENTSOLVENTSOLUTION.
WARNING
SOLVENT SPRAY. THE UNDERSCREEN CLEANER SPRAYS A FINE
JET OF SOLVENT SOLUTION ON TO THE CLEANER. APPROVED
PROTECTIVECLOTHINGSHOULDBEWORN.
WARNING
SOLDERPASTEANDSOLVENTS. WHENUSINGORHANDLINGAN
Y
SOLDER PASTE OR SOLVENT FORMULATION THE
MANUFACTURERS' RECOMMENDED SAFETY PRECAUTIONS
MUSTBESTRICTLYADHEREDTO.
WARNING
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST
COMPLY WITH LOCAL ENVIRONMENTAL GUIDELINES. DE
K
RECOMMEND USINGSOLVENTS THATARE ENVIRONMENTALL
Y
FRIENDLY, IE CFC FREE AND WATER BASED. SOLVENTS USED
MUST HAVE FAST EVAPORATION RATES AND FLASHPOINT
SPECIFICATIONSGREATERTHAN39 C.°
2. Using a suitable container refill the tank and replace the cap.
3.
Press Prime Solvent (F6).
Prime
Solvent
Themessage ‘Press thetwocontrolbuttonstoprimesolvent’isdisplayed.
4. Prime the solvent using the two button control.
5. Remove the head prop. Lower the printhead using two button control.
9.42 User Manual Software Version 6
CONSUMABLE REPLENISHMENTS
VORTEX UNDERSCREEN CLEANER
