10. Press the System button. 11. Select Exit (F8). Exit 12. Select Yes (F1). Yes The message ‘The ProFlow unit will be placed in the REAR envelope’ is displayed. 13. If the ProFlow unit is required to be placed in anothe…
4.
Select Load Cassette (F4).
Load
Cassette
The message ‘Has the ProFlow unit’s base cover been removed?’ is
displayed.
5. If the ProFlow unit’s base cover is still fitted continue with Step 6. If the
ProFlow unit’s base cover has been removed go to Step 12.
6.
Select Remove Cover (F8).
Remove
Cover
The message ‘Open the printer cover and remove the ProFlow unit’s
base cover’ is displayed.
7. Open the printhead cover.
8. Remove the ProFlow unit’s base cover.
9. Close the front printhead cover.
Software Version 6 User Manual 9.51
CONSUMABLE REPLENISHMENTS
PROFLOW
10.
Press the System button.
11.
Select Exit (F8).
Exit
12.
Select Yes (F1).
Yes
The message ‘The ProFlow unit will be placed in the REAR envelope’ is
displayed.
13. Ifthe ProFlow unit is required to be placed in another envelope continue with
Step 14. If the ProFlow unit is required tobe placed inthe machine preferred
envelope go to Step 18.
14.
Select Select Another (F8).
Select
Another
The following window is displayed:
15.
Use the Next or Previous keys (F4 or F5) to highlight Front.
Next Previous
9.52 User Manual Software Version 6
CONSUMABLE REPLENISHMENTS
PROFLOW
Preferred Envelope
REAR
FRONT
16.
Select Use (F1).
Use
17.
Select Exit (F8).
Exit
18.
Select Proceed (F1).
Proceed
The ProFlow unit is placed in contact with the screen.
19. Open the front printhead cover.
Software Version 6 User Manual 9.53
CONSUMABLE REPLENISHMENTS
PROFLOW
