20. Check that the setup of the tooling is adequate for the board, adjust as

necessary.

21.

Select Head (F2).

Head

22. Remove the head prop. Lower the printhead using two button control.

23.

Press the System button.

24.

Select Home Position (F7).

Home

Position

Software Version 6 User Manual 1.27

MACHINE PROGRAMMING

STAGE 6A

25.

Select Raise Head (F2).

Raise

Head

26. Raise the printhead using two button control. Fit the head prop.

27.

Select Board Clamps (F3), to open the clamps.

Board

Clamps

28. Remove the board from the rails.

29.

Select Head (F2).

Head

30. Remove the head prop. Lower the printhead using two button control.

1.28 User Manual Software Version 6

MACHINE PROGRAMMING

STAGE 6A

31.

Press the System button.

32.

Select Exit (F8).

Exit

33. Go to Stage 7.
