MODEL TCM-3500Z 9810-001 8- 1 Key No. PART No. PART NAME Q' ty REMARKS 2 630 064 8218 BASE(CONVEYOR R) 1 678H--02B-001 3 630 053 0629 PLATE 1 678H--02B-004 4 411 141 4107 W ASHER V 5X10X1 2 FW 5 5 411 141 6705 W ASH…
MODEL TCM-3500Z
9810-001
R コンベア部 R CONVEYOR SECTION
Fig. 8-1 コンベア Conveyor
53
53
54
55
57
8-1
60
59
58
7
9
20
18
17
14
15
16
11
12
13
45
28
29
30
27
38
38
43
44
53
42
46
48
47
69
68
67
66
53
10
18
19
21
28
29
30
27-1
55
53
53
3
60
59
58
56
8
36
35
34
37
33
41
40
39
26
25
24
23
22
26-1
36
35
34
37
33
54
53
93
92
91
2
31
32
14
15
16
45
4
5
6
31
32
39
40
46
48
47
53
43
44
42
41
A
A
B
B
D
D
C
C
21
60-1
59
58
4796
-002
79
73
78
77
76
75
74
72
71
79
78
77
76
75
74
71
72
73
E
F
E
F
MODEL TCM-3500Z
9810-001
8- 1
Key No. PART No. PART NAME Q'ty REMARKS
2 630 064 8218 BASE(CONVEYOR R) 1 678H--02B-001
3 630 053 0629 PLATE 1 678H--02B-004
4 411 141 4107 WASHER V 5X10X1 2 FW5
5 411 141 6705 WASHER SPR 5 2 SW5
6 630 000 7749 BOLT,HEX-SCT 2 M5X10
7 630 001 1548 BEARING,RADIAL 2 678H--02H-022
8 630 064 8249 PLATE(MAE) 1 678H--02B-012
8 -1 630 069 7834 PLATE (OKU) 1 678H--02B-011
9 630 064 8225 PLATE,LOCATE(R) 1 678H--02B-003
10 630 053 0612 PLATE,LOCATE 1 678H--02B-006
11 411 141 4107 WASHER V 5X10X1 2 FW5
12 411 141 6705 WASHER SPR 5 2 SW5
13 630 000 7749 BOLT,HEX-SCT 2 M5X10
14 411 141 4305 WASHER V 6X12.5X1.6 6 FW6
15 411 141 3001 WASHER SPR 6 6 SW6
16 630 000 7886 BOLT,HEX-SCT 6 M6X16
17 630 030 5913 COLLAR 2 678H--02B-007
18 630 001 1531 BEARING,RADIAL 4 678H--02H-021
19 630 065 4264 GUIDE,SLIDE 2 678H--02H-024
20 411 000 7805 RING C 20 2 678H--02H-023
21 630 000 8883 SET SCREW 2 M3X4 SET
22 630 008 5303 BEARING,UNIT 2 678H--02H-020
23 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
24 411 141 3001 WASHER SPR 6 4 SW6
25 630 000 7879 BOLT,HEX-SCT 4 M6X12
26 630 000 8920 SET SCREW 2 M4X6 SET
26 -1 630 053 5419 COLLAR 2 678H--02B-025
27 630 065 4295 BALL SCREW 1 678H--02H-010
27 -1 630 065 4288 BALL SCREW 1 678H--02H-011
28 411 141 4008 WASHER V 4X9X0.8 8 FW4
29 411 141 2905 WASHER SPR 4 8 SW4
30 630 000 7657 BOLT,HEX-SCT 8 M4X16
31 630 001 1432 BEARING,RADIAL 2 678H--02H-009
32 411 000 7300 RING C 12 2 678H--02H-004
33 630 031 0566 BEARING,UNIT 2 678H--02H-012
34 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
35 411 141 3001 WASHER SPR 6 4 SW6
36 630 000 7879 BOLT,HEX-SCT 4 M6X12
37 630 031 0573 NUT 2 678H--02H-013
38 630 064 8133 STAY 2 678H--02B-008
39 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
40 411 141 3001 WASHER SPR 6 4 SW6
41 630 000 7886 BOLT,HEX-SCT 4 M6X16
42 630 053 0636 PLATE 4 678H--02B-005
43 630 001 0220 WASHER 4 678H--02H-027
44 630 000 7763 BOLT,HEX-SCT 4 M5X16
45 411 141 0505 NUT HEX 5 4 M5
46 411 054 8506 NUT HEX 4 4 M4 F
47 411 162 1505 SCR PAN 4X20 4 M4X20 PAN
48 630 001 9117 SPRING,TENSION 4 678H--02H-003
NOTE
MODEL TCM-3500Z
9810-001
8- 1
Key No. PART No. PART NAME Q'ty REMARKS
53 630 031 0399 BEARING,RADIAL 66 678H--01H-001
54 630 067 3111 BELT,ROUND 2 678H--01H-002
55 630 067 3128 BELT,ROUND 2 678H--01H-038
56 630 067 2572 GUIDE(MAE) 1 678H--01B-014
57 630 067 2565 GUIDE(OKU) 1 678H--01B-013
58 411 141 4008 WASHER V 4X9X0.8 10 FW4
59 411 141 2905 WASHER SPR 4 10 SW4
60 630 000 7664 BOLT,HEX-SCT 9 M4X20
60 -1 630 000 7657 BOLT,HEX-SCT 1 M4X16
66 630 056 2743 PLATE(L) 1 678H--01B-048
67 411 141 4008 WASHER V 4X9X0.8 4 FW4
68 411 141 2905 WASHER SPR 4 2 SW4
69 630 000 7602 BOLT,HEX-SCT 2 M4X6
71 630 056 2736 PLATE 2 678H--02B-049
72 630 000 0252 SENSOR,PHOTO 2 678H--02H-044
73 630 000 0269 SENSOR,PHOTO(CONNECTOR) 2 678H--02H-045
74 411 088 9005 WASHER F 3X6X0.5 8 FWS3 F
75 411 086 4408 WASHER SPR 3 4 SW3 F
76 411 040 7803 SCR PAN 3X12 4 M3X12 PAN
77 411 141 4008 WASHER V 4X9X0.8 4 FW4
78 411 141 2905 WASHER SPR 4 4 SW4
79 630 000 7619 BOLT,HEX-SCT 4 M4X8
91 630 001 0237 WASHER 2 678H--01H-025
92 411 141 3001 WASHER SPR 6 2 SW6
93 630 000 7886 BOLT,HEX-SCT 2 M6X16
NOTE
