2.5 Lubricating the T ape Feed Lever Arrow marks in the illustration indicate lubrication points. AFC Grease Daphne Eponex No. 2 ✔ N/A N/A ✔ CP6M3021 Lubrication Points Lubrication Frequency Types of Lubricants 37 38 Eve…
2.4 Lubricating the Cam Turret
Arrow marks in the illustration indicate lubrication points.
Wave
washer
Linear guide
Shaft
Turret groove
Gear
CP6M3020
(32)
(33)
(34)
(35)
(36)
AFC Grease
Daphne
Eponex No. 2
N/A
N/A
✔
✔
N/A
✔
✔
N/A
N/A
✔
CP6M3019
Lubrication
Points
Lubrication
Frequency
Types of Lubricants
32
33
34
35
36
Every month
Every month
Every month
Every month
Every 3 months
✔ : Lubricate N/A : Do not lubricate
Cam groove
Gear
LM rail
Shaft
Wave washer
Part 3 Chapter 2 Lubrication
Edition 1.2 3-2-9 CP-6-series Mechanical Reference
2.5 Lubricating the Tape Feed Lever
Arrow marks in the illustration indicate lubrication points.
AFC Grease
Daphne
Eponex No. 2
✔
N/A
N/A
✔
CP6M3021
Lubrication
Points
Lubrication
Frequency
Types of Lubricants
37
38
Every month
Every month
✔ : Lubricate N/A : Do not lubricate
Cam lever
Shaft
Part 3 Chapter 2 Lubrication
Edition 1.2 3-2-10 CP-6-series Mechanical Reference
2.6 Lubricating the Cam Box
Arrow marks in the illustration indicate lubrication points.
Note: Apply AFC grease to the lever bearing and thrust washer used on the lever pivot.
Toward the front
Bearing side
(42)
Cam side
(40)
Plane cam
(40)
Barrel cam
Connecting pin
(43)
ST 3,10,12,13 rod
Lever pivot
Lever pivot
CP6M3024
(39)
(41)
(41)
AFC Grease
Daphne
Eponex No. 2
N/A
N/A
✔
N/A
N/A
N/A
✔
✔
N/A
✔
✔
✔
CP6M3023
Lubrication
Points
Lubrication
Frequency
Types of Lubricants
39
40
41
42
43
Every week
Every month
Every month
Every month
Every month
Every month
✔ : Lubricate N/A : Do not lubricate
Barrel cam
Plane cam
Lever pivot
Lever bearing
ST3, 10, 12, 13 pins
Rod connecting pins
Part 3 Chapter 2 Lubrication
Edition 1.2 3-2-11 CP-6-series Mechanical Reference
