2.17 Lubricating the Carrier System Conveyor <CP-643E/643ME only> Arrow marks in the illustration indicate lubrication points. Note: The in-conveyor is depicted in the figure above but the same lubrication areas al…
2.16 Lubricating the Rear Cover
<CP-642/CP-643 Series with Rear Cover>
Arrow marks in the illustration indicate lubrication points.
CP6M3045
(69)
Rear cover ball catch fasteners
Ball catch
Daphne Eponex No. 2
✔
CP6M3044
Lubrication
Point
Lubrication
Frequency
Type of Lubricant
69
Every 3 months
✔ : Lubricate
Part 3 Chapter 2 Lubrication
Edition 1.2 3-2-22 CP-6-series Mechanical Reference
2.17 Lubricating the Carrier System Conveyor
<CP-643E/643ME only>
Arrow marks in the illustration indicate lubrication points.
Note: The in-conveyor is depicted in the figure above but the same lubrication areas also apply to
the out-conveyor.
CP6M3047
Middle stopper
Guide bars
(74)
(74)
(73)
(71)
(71)
(72)
(71)
Ball screw
Shaft
Stopper's bearing
Guide bar
Daphne Eponex No.2
✔
✔
✔
✔
CP6M3046
Lubrication
Points
Lubrication
Frequency
Types of Lubricants
71
72
73
74
Every month
Every month
Every month
Every month
✔ : Lubricate
Part 3 Chapter 2 Lubrication
Edition 1.2 3-2-23 CP-6-series Mechanical Reference
2.18 Lubricating the Carrier <CP-643E/643ME only>
Arrow marks in the illustration indicate lubrication points.
Note: The in-carrier is depicted in the figure above but the same lubrication areas also apply to
the out-carrier.
CP6M3049
(75)
(76)
(75)
(75)(75)
LM rail
Cam follower
Daphne Eponex No.2
✔
✔
CP6M3048
Lubrication
Points
Lubrication
Frequency
Types of Lubricants
75
76
Every month
Every month
✔ : Lubricate
Part 3 Chapter 2 Lubrication
