Part 8

Pallet Feeder

- CP-652CE Only -

1. Pallet Feeder

The CP-652CE uses a pallet system to feed parts, thus eliminating the device Tables.

Pallets are transferred using a D-axis carrier driven by a timing belt and ball screw.

When the pallets are empty they are ejected from the D-axis carrier area and recirculated

in a counterclockwise direction as seen from the rear of the machine.

1 - 30D

Pallet

CP6M9001

Viewed from the rear side of the machine

Part 8 Chapter 1 Pallet Feeder

Edition 1.0 8-1-1 CP-6-series Mechanical Reference
