4 – 6

Components

SSOP/DIL C & P-20 C & P-12 C & P-6 P&P Head Twin Head

Package Form (GF)

[L4W4H (mm)] GF File Nozzle Types

SSOP 48_0.025

[15.9410.342.7]

523

920 920

817* 516 516

SO 32X

[21.1413.842.5]

SO 40X

[26.2413.6542.4]

SO 40Y

[26.2414.2542.5]

524

525

526

920

817* 517 517

4 – 7

TSSOP 20

[6.546.441.4]

541

937 937 516 516

DIL 4

[4.849.744.8]

570

939 939

DIL 6

[8.6410.044.4]

DIL 8

[9.3410.044.4]

571

572

937 937 516 516

SO 8_high_OK8

[4.946.043.2]

582

1135* 935 935

Comments:

4 – 8

Components

TSOP C & P-20 C & P-12 C & P-6 P&P Head Twin Head

Package Form (GF)

[L4W4H (mm)] GF File Nozzle Types

TSOP 24_20

[16.046.041.2]

600

937 937 516 516

TSOP I 24

[20.046.041.0]

601

937 516 516

TSOP 32

[20.0410.141.0]

602

920

817* 516 516

Comments:
