8 – 5 Special Nozzles La mp ; 5 Alba, SMD45 Power LE D ; 4.8 Cree, Xlamp LED XR-E 0033 2598 0033 2598 LED TO PLED with l ens Toshiba, TLPGE1102 L E D 12 0 6 with l ens Stanley, F1105W Series; Kingbright, KPTD-3216 003596…
8 – 4
Tested
Components C & P-20 C & P-12 C & P-6 P&P Head Twin Head
Package Form
[L4W4H (mm)] Nozzle Types
Tracer 4P
ITT, KSC3xxJ
[7.046.443.2]
Switch 5P
ITT, RTE 10
[7.4410.047.65]
Switch 5P
ddm hopt+schuler
[10.047.344.2]
00348516 00348516
Comments:
8 – 5
Special
Nozzles
Lamp ;5
Alba, SMD45
Power LED ;4.8
Cree, Xlamp LED XR-E
00332598 00332598
LED TOPLED
with lens
Toshiba, TLPGE1102
LED 1206
with lens
Stanley, F1105W Series;
Kingbright, KPTD-3216
00359602 00359602
LED TOPLED
with lens
Osram, LY E656, E655,
LA E65B, SFH 3219
00355425 00355425
Comments:
8 – 6
Tested
Components C & P-20 C & P-12 C & P-6 P&P Head Twin Head
Package Form
[L4W4H (mm)] Nozzle Types
LED TOPLED
Osram, LS T676, LA T676,
LO T676, LY T676
Tracer 4P
Panasonic, EVQP701C
[3.5544.741.35]
03055475 03055475
Clip
[4.2544.2]
00350557 00350557
Comments:
