8 – 8 Te s t e d Component s C & P-20 C & P-12 C & P- 6 P &P Head Tw i n H e a d Package F o rm [L 4 W 4 H (mm)] Noz zle T y pes Con nec tor 3 0 p _1. 0 FPC/FFC top Hirose, FH12-30S-0.5SV Con nec tor 4p _…
8 – 7
Special
Nozzles
Connector
3p_1.25 male top
Hirose, DF13B-3P-1.25V
Connector
2p_1.5 male top
JST, B2B-ZR-SM3F
00344275 00344275
Connector
50p_0.4 female top
Molex, 55909-0575
Connector
40p_0.40
03031910 03031910
Comments:
8 – 8
Tested
Components C & P-20 C & P-12 C & P-6 P&P Head Twin Head
Package Form
[L4W4H (mm)] Nozzle Types
Connector
30p_1.0 FPC/FFC top
Hirose, FH12-30S-0.5SV
Connector
4p_2.54 male side
SNBHY-4
Connector
10p_2.0 FPC/FFC top
Framatome, SFW10S-2STM
00350703 00350703
Connector
3p_1.27 female top
Samtec, CLP-115-02-G-D-K
03004338 03004338
8 – 9
Special
Nozzles
Connector
40p_0.5 FPC/FFC side
Kyocera
03030085 03030085
Relais
10p_2.54
NEC, EB2-9NU; EB2-5NU
[14.1411.546.8]
Choke Coil 2P
Coilcraft, DS5022P
[18.0415.047.0]
03012580 03012580
Comments:
