- - REF.NO NOT E PART NO D E S C R I P T I O N Qty 1 400-73032 4 PORT MPC 1 2 HX-0066000-00 DUST COVER 3 3 400-73033 SWITCHING HUB 1 4 401-13917 MPC_BR 1 5 SL-6030892-TN SCREW 4 6 401-13918 HUB_BR 1 7 400-71597 CAREER_…
- -
56.RFID COMPONENTS (MPC)
5
1 7
1 2
1 3
1 4
1 5
4
1
1 0
9
3
6
7 8
2
2
1 1
1 6
2
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-73032 4 PORT MPC 1
2 HX-0066000-00 DUST COVER 3
3 400-73033 SWITCHING HUB 1
4 401-13917 MPC_BR 1
5 SL-6030892-TN SCREW 4
6 401-13918 HUB_BR 1
7 400-71597 CAREER_RAIL_30 1
8 SL-4040891-SC SCREW M4 L=8 2
9 SL-6030592-TN SCREW M3 L=5 2
10 SL-6061492-TN BOLT 1
11 SL-3061232-TN SCREW 2
12 EA-9500B01-00 CABLE BAND 20
13 EA-9500B02-00 CABLE BAND 150 20
14 HX-0006500-0C CABLE BAND 10
15 HX-0031400-0C SPIRAL TUBE 0.5
16 HX-0006500-0B CABLE BAND 2
17 EA-9500B01-00 CABLE BAND 1
- -
57.RFID COMPONENTS (REPLACING OVERALL CHANGER TRUCK)
1
2
4
3
6
5
8
7
1 0
9
4
