FX-3-Rev13(k-) - 第38页
- - 17. X-Y COMPONEN TS (3)(RIGHT STATION) 5 6 6 7 7 6 8 8 7 8 1 5 1 4 1 6 1 7 2 6 2 7 7 6 7 8 7 5 7 4 9 4 7 6 7 8 7 5 2 3 7 7 6 1 8 0 6 1 8 0 8 4 8 3 8 5 8 7 2 9 8 8 9 0 9 3 9 6 9 3 9 6 2 0 8 1 7 7 1 5 1 4 1 6 1 7 9 7…
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1
#01
400-93052 LINEAR MOTOR STATOR 4
2
#01
400-93163 Y LINEAR GUIDE XL 2
3 400-02227 X PLUS LMT SENSOR ASM 4
4 400-48018 LINEAR MOTOR STATOR 1
5 SM-6051602-TN BOLT 72
6 400-46713 Y STOPPER 4
7 SM-6126002-TN SCREW M12 L=60 4
8 PA-9000740-00 SHOCK ABSORBER 4
9 400-90280 RUBBBER FEET 4
10 E2779-721-000 STOPPER COLLAR 4
11 SM-4031201-SC SCREW M3 X 12 4
12 HX-0034400-00 HARNESS PARTS 1
13 SL-4030691-SC SCREW M3X6 4
14 400-46720 FSD BRACKET 2
15 SL-6051292-TN BOLT 4
16 E2157-729-000 FSD SPACER 2
17 SL-4031481-SC SCREW M3 X 14 8
18 HX-0029400-00 FIXED BASE 20
19 SM-4040601-SC SCREW M4X0.7 L=6 20
20 400-70189 CAUTION LABEL 80 3
21 400-02229 X ORG RANGE SENSOR ASM 4
22 400-82676 Y FRAME END FAN CABLE E ASM 1
23 400-47495 FD-FLOAT(FF)SENS ASM 1
24
#01
400-46729 Y LMT BRACKET 4
25 SL-6040892-TN BOLT 8
26 400-47496 FD-FLOAT(FF)RECEIVE SENS ASM 1
27 400-47497 FD-FLOAT(FR)SENS ASM 1
28
#01
400-93158 MSC GUARD C XL 4
29 SL-6041092-TN SCREW 12
30 HX-0009600-00 GROMMET 0.03
31
#01
400-94162 Y LINEAR BASE S ASM XL 2
32 400-94103 Y LINEAR BASE S ASM 2
33 SM-6051602-TN BOLT (16)
34 SL-6052592-TN BOLT (6)
35 SM-6051602-TN BOLT (12)
36 SL-6052592-TN BOLT (3)
37 HX-0029400-00 FIXED BASE (7)
38 SM-4040601-SC SCREW M4X0.7 L=6 (7)
39 400-90280 RUBBBER FEET (1)
40 400-47385 Y LINEAR BASE S (1)
41 SM-4031201-SC SCREW M3 X 12 (2)
42 400-98018 Y MSH BRACKET S (1)
43 SL-6041292-TN SCREW (2)
44 SL-6030892-TN SCREW (2)
45 SM-4040601-SC SCREW M4X0.7 L=6 (2)
46 HX-0034400-00 HARNESS PARTS (2)
47 400-47390 MSU BRACKET (2)
48 SL-6040892-TN BOLT (2)
49 SL-6030692-TN BOLT (4)
50 400-47387 LINEAR SCRAPER BRACKET (1)
51 SL-6041292-TN SCREW (2)
52 400-47388 LINEAR SCRAPER (2)
53
#01
SL-6030892-TN SCREW (4)
54 400-66149 Y FAN60 BRACKET S (1)
55 SL-6040892-TN BOLT (4)
56 400-66151 Y HEAT SINK S (1)
57 SL-6041092-TN SCREW (3)
58 400-93510 Y FAN GUARD C (4)
59 SL-4042591-SC SCREW M4 L=25 (6)
60 400-46708 LINEAR GUIDE Y 4
61 400-46740 MSC GUARD 4
62 E2333-715-000 CAUTION SEAL 4
63 400-48018 LINEAR MOTOR STATOR 1
64 SM-6051602-TN BOLT 72
65 400-46713 Y STOPPER 4
66 SM-6126002-TN SCREW M12 L=60 4
67 PA-9000740-00 SHOCK ABSORBER 4
68 400-90280 RUBBBER FEET 4
69 E2779-721-000 STOPPER COLLAR 4
70 SM-4031201-SC SCREW M3 X 12 4
71 HX-0005600-0A SPACER B 1
72 NM-6030001-SC NUT M3 1
73 400-70397 FD-FLOAT(RF)SENS ASM 1
74 400-70398 FD-FLOAT(RF)RECEIVE SENS ASM 1
75 400-46720 FSD BRACKET 2
76 SL-6051292-TN BOLT 4
77 E2157-729-000 FSD SPACER 2
78 SL-4031481-SC SCREW M3 X 14 8
79 400-82672 Y FRAME END FAN CABLE D ASM 1
80
#01
400-93159 MSC GUARD S XL 2
81 SL-6051092-TN BOLT 6
82
#01
400-93370 CABLE BEAR Y XL 2
83 SL-6061292-TN SCREW 8
84 400-46721 PLASTIC RAIL SUPPORT Y 2
85 SM-3061252-TN SCREW M6 L=12 8
86 401-02721 CABLE_CLAMP_YF 1
87 400-47386 CABLE CLAMP RUBBER Y 2
88 SL-6061292-TN SCREW 4
89 400-46722 CB BRACKET YC 1
90 SL-6062592-TN SCREW 2
91 400-46727 CB BRACKET YSA 2
92 SL-6061292-TN SCREW 4
93 HX-0022300-0A BUSHING 1
94 400-70399 FD-FLOAT(RR)SENS ASM 1
95 400-44532 MAGNETIC SCALE Y SENOR UNIT 4
96
#01
400-48080 MAGNETIC SCALE Y XL 2
97 400-70400 FD-FLOAT(RR)RECEIVE SENS ASM 1
98 400-82671 Y FRAME END FAN CABLE C ASM 1
99 400-47984 Y LINEAR MOTOR ASM 2
100 400-82670 Y FRAME END FAN CABLE B ASM 1
101
#01
400-93163 Y LINEAR GUIDE XL 2
102 400-47498 FD-FLOAT(FR)RECEIVE SENS ASM 1
103 HX-0034400-00 HARNESS PARTS 1
104 SM-3040652-TN SCREW M4 L=6 1
105 WP-0450816-SC WASHER 1
106 NM-6040003-SC NUT M4 1
107 400-81949 CABLE CLAMP YN 1
108 HX-0009600-0A GROMMET 0.44
109 HX-0029400-00 FIXED BASE 3
110 400-47389 MSC GUARD S 2
111 400-46709 CABLE BEAR Y 2
112 400-91396 MAGNETIC SCALE Y 2
- -
