3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer
3.1 Initial Installation of SIPLACE Explorer 2.7 Edition 03/2010 EN
26
NOTE
Before you install SIPLACE Explorer V2.7, make sure that SIPLACE License Manager 2.0
has been installed on your computer. Install this software component via the support media
DVD. 3
NOTE
Before you install SIPLACE Explorer V2.7, make sure that Java 1.6 has been installed on
your computer. Install this software component via the support media DVD. 3
WARNING
Do not install "SIPLACE Explorer V.2.7 Runtime Environment" and "SIPLACE Explorer V.2.7
Development Environment" on the same computer. These two options will not run parallel to
one another. Before working with these options in succession, make sure you know the steps
for starting/terminating the respective option and observe these. 3
(2)Support Media DVD:
The system will be checked for the required software components and their versions. You will
see the result of this check in a notifications window and can then install any missing
components via this option. 3
The following software components are included on the support media DVD and will be
installed when required: 3
– J2SE Runtime Environment 6 update 1 or higher
Install Java 6 update 1 on the same computer as SIPLACE Explorer V.2.7. 3
– Tomcat 5.5
– MS XML Core Services 6.0
Install these components if you wish to generate factory reports and reports for certain
production lines. 3
– SQL Server 2008 Express Edition
Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer
Edition 03/2010 EN 3.1 Initial Installation of SIPLACE Explorer 2.7
27
– Microsoft Internet Explorer 6.0 SP2 or 7.0
Microsoft Internet Explorer is required to view and edit websites. 3
Microsoft Internet Explorer 6.0 SP2 is included on the Support Media DVD, MS Internet
Explorer 7.0, installed with the Windows Vista installation. 3
– Adobe Reader 7.0
This component is needed for reading the SIPLACE Explorer V.2.7 documentation. Adobe
Reader 7.0 is included on the Support Media DVD. 3
For a detailed description of the specified installations, refer to the document “Navigation
Guide for the Installation Procedure of SIPLACE Software Systems” (Art.No. 00195050-xx).3
Consider the following before beginning the installation: 3
NOTE
Before installing Tomcat 5.5, make sure that all versions of Tomcat < 5.5 have been
uninstalled. Use the Apache Tomcat uninstallation program. This can be started via the
Start → Programs → Apache Tomcat 5.5 → Uninstall Tomcat menu in Windows. 3
NOTE
You will need to specify the following information when installing Tomcat 5.5:
- Port number for Tomcat: By default, Tomcat is installed on port 8080. This means that your
users will access your website as follows:
http://yourServerName:8080/yourWebsite/index.jsp.
- Access data for the Tomcat administrator:
User name: admin
Password Policy: depending on the selected password policy, you need to enter a
password: MS128 or Siplace.1.
This password is needed for website generation.
This login will automatically be used as default login for Line Configuration - Step 7 "Website
Generation". 3
3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer
3.1 Initial Installation of SIPLACE Explorer 2.7 Edition 03/2010 EN
28
NOTE
Before you install SIPLACE Explorer V2.7, make sure that Java 1.6 has been installed on
your computer. Install this software component via the support media DVD. 3
(3)SIPLACE Explorer V.2.7 options:
The options SIPLACE Traceability Option V2.0 and SIPLACE Maintenance Manager V1.0 are
not included in the SIPLACE Explorer V2.7 delivery package and must be ordered (installed)
separately. 3
3.1.1 Installation of SIPLACE Explorer 2.7 - Initial Installation
NOTE
You must have Windows administrator privileges to perform installation. 3
→ Place the support media DVD in your DVD drive. Follow the instructions in the document
“Navigation Guide for the Installation Procedure of SIPLACE Software Systems” (Art.No.
00195050-xx).
→ Place the SIPLACE Explorer CD in your CD-ROM drive. The Start screen will open.
3
Fig. 3 - 1 SIPLACE Explorer setup - Start screen
