Excellent Modular Component Placer EXCEN Series EXCEN PRO(M)/(D)/(L) Technical Reference - 第113页
Page +$1:+$ 107 Cover Door(DT) EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L) NO. P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference A AM03-0177 92A PRO-DT_DOOR_L_ ASSY 2 B AM03-0177 94A PRO-DT_DOOR_R _ASSY 2 1 F…
Page
+$1:+$
106
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Cover Door(DT)
2
1
Direct Tray Option
3
Direct Tray Option
3
AB
Page
+$1:+$
107
Cover Door(DT)
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
A AM03-017792A PRO-DT_DOOR_L_ASSY 2
B AM03-017794A PRO-DT_DOOR_R_ASSY 2
1 FC29-002623A HINGES-HINGE 2 FC29-000833B
2 FC29-000007 CAP-PULL;AP-268-2-BLACK,PL15:ABS 1
3 FC15-001871A COVER-DT_DOOR_BLOCK 1 Direct Tray Cover Dedicated
