Excellent Modular Component Placer EXCEN Series EXCEN PRO(M)/(D)/(L) Technical Reference - 第137页
Page +$1:+$ 131 EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L)
Page
+$1:+$
130
Docking Cart(1/3) - Direct Tray Docking Cart Option
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
28 MC03-000005 BEARING,BALL-BALL_BUSH;LMK25LUU 2
29 FC10-000042 CUSHION,RUBBER-Urethane AYMK30-15 2
30 FC09-007422A BRACKET-DC_BUSH_BRACKET 1
31 FC30-000910F PLATE-LOCATE_PLATE_F 1
32 FC30-001906C PLATE-DC_TAPE_GUIDE_C 1
33 FC30-002594A PLATE-V1P08-PCB_SHIELD_PLATE 1
34 FC15-005201A COVER-DC_BOARD_COVER_A;: 1
Page
+$1:+$
131
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
Page
+$1:+$
132
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Docking Cart(2/3) - Direct Tray Docking Cart Option
7
4
8
9
10
16
17
11
6
18
5
4
3
14
15
23
22
1
2
24
5
12
19
21
20
13
