Page +$1:+$ 135 Docking Cart(3/3) - Direct Tray Docking Cart Option EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L) NO. PA R T N O . P ART NAME Q'TY Old No. Supp ly Supply L T Reference 1 FC08-0000 99A BOX-V1P08-DUMP_BOX_520…
Page
+$1:+$
134
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Docking Cart(3/3) - Direct Tray Docking Cart Option
28
15
17
27
27
11
6
9
6
21
21
39
35
22
23
6
19
37
36
38
30
32
33
34
26
31
4
7
11
8
29
40
24
12
24
20
18
6
5
25
22
13
14
16
2
1
3
10
H950
Page
+$1:+$
135
Docking Cart(3/3) - Direct Tray Docking Cart Option
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 FC08-000099A BOX-V1P08-DUMP_BOX_520 1
2 FC29-002881A GUIDE-V1P08-DUMP_BOX_GUIDE_MUSEUN 1
3 FC35-000137A ROLLER-V1P08-ROLLER_FIXER 2
4 RM01-001003A BAR-V1P08-ROLLER_BAR;STS303,CIRCLE 3
5 FC35-000134A ROLLER-V1P08-ROLLER_21 32
6 FC18-901368 C-RING 3
7 FC09-006247A BRACKET-DC_ROLLER_SUPPORT_BKT 1
8 J70653874A COLLAR J70653874A 1
9 J70653877A SHAFT_C J70653877A 1
10 J70653897A LILLE_PLATE J70653897A 32
11 FC29-003623A POST-V1P08-UPPER_REEL_POST 32
12 FC30-004295A PLATE-V1P08-PARTITION_C 5
13 J70653892A PARTITION_HOLDER J70653892A 1
14 FC09-007423A BRACKET-DC_STOPPER_BKT 1
15 FC15-001458B COVER-CHUTE_ACRYL_C;ACRYL,PLATE 1
16 FC29-900016 END-CAP 2
17 FC38-900064 SPRING WT16-20 1
18 J70653891A SUB_LILLE_HOLDER J70653891A 16
19 J70653876A SHAFT_B J70653876A 1
20 MC19-000417A SHAFT-V1P08-SHAFT_D 2
21 FC10-900011 GRIP C-31-3-EP-UL 2
22 RM01-003091A BAR-HANDLE-DC_HANDLE_CD;STS304 2
23 FC09-001999A BRACKET-V1P08-BAR 2
24 FC30-001016A PLATE-V1P08-325-SIDE_COVER_SUPPORT 2
25 FC30-004914A PLATE-DC_SIDE_COVER_L 1
26 FC29-007661A CHUTE-DC_CHUTE 1
27 J70653875A SHAFT_A J70653875A 2
28 FC09-900009 BRACKET 4
29 MC14-000003 CASTER,WHEEL-CASTER;K-612ES-65-N2,65,25 2
30 RM01-003035A BAR-DC_REEL_BAR_N;STEEL 1
31 FC09-001999A BRACKET-V1P08-BAR 2
Page
+$1:+$
136
Docking Cart(3/3) - Direct Tray Docking Cart Option
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 FC30-004913A PLATE-DC_SIDE_COVER_R 1
33 FC30-004916A PLATE-DC_FRONT_COVER 1
34 FC09-900010 BRACKET 2
35 FC30-004708A PLATE-DC_CASTER_PLT 2
36 FC18-003080A SPACER-COLLAR_CASTER 8 H900/ H900 ESD
FC29-006546A COLLAR-FRONT_CASTER_COLLAR_950;STRAIGHT, 8 H950/ H950 ESD
37 MC14-000088 CASTER,WHEEL-103-N;UCHIMURA,50,22,65,80 2
38 MC14-000003 CASTER,WHEEL-CASTER;K-612ES-65-N2,65,25 2 H900/ H950
MC14-000045 CASTER,WHEEL-CSMSNSU65A 2 H900 ESD/ H950 ESD
39 FC18-000934B SPACER-BOX_SPACER 6
40 FC18-000245A SPACER-SPACER_H950 2 H950/ H950 ESD
