Excellent Modular Component Placer EXCEN Series EXCEN PRO(M)/(D)/(L) Technical Reference - 第184页
Page +$1:+$ 178 MFH(4/4) (Option) EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L) NO. P ART NO. P ART NAME Q'T Y Old No. Supply Supply L T Reference 32 FC1 8-000541 RIN G ,O-ORING -46X08_FPM 2 33 MC06-000027A BUSHING-V021-BU…
Page
+$1:+$
177
MFH(4/4) (Option)
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 FC30-000632A PLATE-V020-BEARING_PLATE_B01 1
2 AM03-004876A ASSY,HEAD-HSH_COLLAR_SUB_ASSY_AS 1
3 J70551759A V020-OUTER_COLLAR 1
4 HP12-000084 SEAL-SEAL_IW-0102 3
5 J71551486A V020-SEAL_SPACER 2
6 FC18-901416 O_RING FC18-901416 3
7 J70551757A V020-INNER_COLLAR 1
8 FC18-901420 O_RING FC18-901420 3
9 MC03-000096 BEARING,BALL-BEARING-7905CTYNDBC7A-IJK 2
10 AM03-004017A ASSY,HEAD-MFH_BARREL_SHAFT_SUB_ASSY 1
11 MC03-900107 BALL_BEARING 2
12 J71551494A V021-BARREL_SHAFT 1
13 FC18-901418 O_RING FC18-901418 1
14 FC18-901417 O_RING FC18-901417 2
15 J70551789A V021-SPINDLE_HEAD 1
16 J70551791A V021-SPRING_HOLDER 1
17 MC03-900011 BEARING [MR84zz (NSK)] 1
18 J70551790A V021-SPINDLE_SPRING 2
19 FC29-000742A COLLAR-V021-SPRING_COLLAR_C 1
20 AM03-015097A ASSY,HEAD-MFH_SPLINE_UNIT_SUB_ASSY 1 AM03-004021A
21 MC03-900078 MINIATURE_BEARING MR117ZZ 1
22 MC13-000309 SPLINE,BALL-MFH_BALL_SPLINE_38_NO_PIN 1 MC13-000009C/ MC13-000082A
23 MC03-900064 BALL_BEARING MR128ZZ 1
24 MC11-000585B GEAR,SPUR-V021-SPINDLE_GEAR_A_C 1
25 J70551798A V021-GEAR_SPACER 1
26 J70551797A V021-S_GEAR_SPRING 1
27 MC11-000586A GEAR,SPUR-V021-SPINDLE_GEAR_B_B 1
28 FC29-001310A HOLDER-HSH_V020-ZON_HOLDER_ASSY 3
29 FC30-002028B PLATE-MF_BOTTOM_PLATE_INNER 1 FC30-002028A
30 FC28-000673B POLE-MF-SUPPORT_POLE 4 FC28-000673A
31 FC29-002985A HOLDER-MFH_NOZ_HOLDER_38 1 FC29-000393A/ FC29-000393B
Page
+$1:+$
178
MFH(4/4) (Option)
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 FC18-000541 RING,O-ORING-46X08_FPM 2
33 MC06-000027A BUSHING-V021-BUSH_C2 1
34 FC29-000390A STOPPER-STOPPER BUSH 1
35 AM03-004023A ASSY,HEAD-MFH_BOTTOM_PLATE_SUB_ASSY 1
36 FC15-002460B COVER-MF_BOTTOM_PLATE_OUTER 1 J71551498A /FC15-002460A
37 FC28-000672A POLE-MF-REF_POLE 2 J71551484A
38 FC18-000965 E-RING 1
39 FC07-001379A BLOCK-MF-REF_PROTECT_BLOCK 1
40 J70551796A V021-T_SHAFT 1
41 MC19-900008 PARALLEL_KEY 1
42 J70552006A V020-COLLAR_T_SHAFT 1
43 MC11-000587A GEAR,SPUR-V021-T_GEAR_D_B 1
44 FC18-000345A NUT,LOCK-V020-LOCK_NUT_T-01 1
45 AM03-008814A ASSY,HEAD-V1P_VALVE_SUB_ASSY 8
46 HP15-000001D SPOOL-V020-SPOOL;ME1:Steel 1 HP15-000001A /HP15-000001C
47 FC18-901415 O_RING FC18-901415 5
48 FC18-901419 O_RING FC18-901419 4
49 HP14-000099A VALVE-V020-VALVE_BODY 1
50 FC18-901414 O_RING 1
51 HP14-900122 CHECK_VALVE 1
52 FC30-002253A V020-CAP_SCREW 1 J71551477A
53 HP12-000117 SEAL-M-5G2 1
54 HP04-000049A FILTER-AIR_FILTER 1
55 FC10-000058A SPONGE-V1_VALVE_CUSHION 1
56 FC29-003360A CAP-FILTER_CAP 1 FC29-001329A
57 J70551760A V020-PIN_S 1
58 J70552009A PIN-JIS_B_D1H7L5 8
59 EP14-000300A BARREL-V021-BARREL 1
60 J71551497A V021-BEARING_HOLDER_B 2
61 MC03-000138 BEARING,BALL-BEARING_7900CTYNDBC7_IJK 2
62 FC30-000631A PLATE-V020-BEARING_PLATE_A01 1
Page
+$1:+$
179
MFH(4/4) (Option)
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
63 RM01-000279D PLATE-MF_BEARING_PLATE_BC;MIGRATION 4 RM01-000279C Site repair
FC30-004695A PLATE-BEARING_INNER_PLATE 4
64 FC18-001197A SPACER-MF-REF_SPACER 4 FC18-000374A
